MCCORMICK X60.30 - Check Function of the Operator Presence Switch

205
Maintenance
7
9
500 HOUR MAIN SERVICE
Check function of the operator
presence switch
Checktheswitchforcorrectfunctionevery500hoursof
operationoratleastonceannually.Whendoingthefol-
lowingchecks,dosoinaclearopenareawithnoother
personsorobjectsnearthetractor:
OPERATION1
Engagetheparkingbrakeand a gear. Get up from the
seat:thebuzzershouldsound.
OPERATION2
Whilesittingontheoperator'sseat,withtheenginerun-
ningatlowidlespeed,andtheF-N-RleverinNEUTRAL,
withoutengagingtheparkingbrake,engagethe1stgear
andtheslowrange,andreleasetheclutchpedal.Standup
outoftheoperator'sseatwhileholdingontothesteering
wheelandmovetheF-N-RleverfromNEUTRALtoeither
FORWARDorREVERSE.Thebuzzersoundsandtheindi-
catorsN(neutral)andtheforwardorreversearrowblink
ontheinstrumentcluster.ThetractorMUSTNOTmove.
Ifthetractormoves,seeyourdealerforrepair.
OPERATION3
Whilesittingontheoperator'sseat,withtheenginerun-
ningatlowidlespeed,puttheF-N-RleverinFORWARD,
thetransmissionin1stgearandslowrangerangeand
releasetheclutchpedaltostartthetractormoving.The
tractorshouldstartslowly.Standupoutoftheoperator's
seat while holding onto the steering wheel, and move
the FNR lever out of the FORWARD position into the
REVERSEposition.Thebuzzersoundsandtheindicator
N(neutral)blinksontheinstrumentcluster.Thetractor
MUST stop (default to Neutral). If the tractor does not
defaulttoNeutral,seeyourdealerimmediatelyforrepair.
IMPORTANT: DO NOT bypass the operator
presence circuit. Otherwise the situation can
be risky both for the operator and the people
near the tractor.
If the operator presence switch circuit is
bypassed, the electronic system will sense
the change and transmit the error code. The
exclamation point in the instrument cluster
will light up. The circuit must be enabled in
any case.
WARNING: Always use specific personal safety devices
for each operation.
