What to do if McCrometer Ultra Mag Measuring Instruments shows 420 ERR?
If your McCrometer Measuring Instruments display shows a '420 ERR' message, it means the 4-20 circuit is not wired correctly. To fix this, check the wiring diagram and make sure 9-30VDC power is supplied to the circuit. Remember that the output is not source powered.
What to do if McCrometer Measuring Instruments displays ADC CLIP?
If your McCrometer Measuring Instruments display shows 'ADC CLIP', it means the meter signal exceeds the limit of the converter, likely due to noise. Ensure the meter grounding meets the IOM guidelines and identify any sources of noise.
How to fix HIGH HUM on McCrometer Ultra Mag Measuring Instruments?
If your McCrometer Measuring Instruments displays 'HIGH HUM', it indicates that humidity inside the converter housing has exceeded limits. Check for any loose connections on the converter housing that could be creating a leak.
What to do if McCrometer Ultra Mag Measuring Instruments shows BAT LOW?
If your McCrometer Measuring Instruments display shows 'BAT LOW', a battery replacement Kit is needed to replace batteries. The batteries Should last approximately 6-9 months from the time the warning is shown.
Why does McCrometer Measuring Instruments show COIL XCT?
If your McCrometer Measuring Instruments display shows 'COIL XCT', it indicates an issue with the electro magnetic coils. Check that the internal wiring is correct in the converter for the coil wires.
What to do if McCrometer Ultra Mag Measuring Instruments displays COIN LOW?
If your McCrometer Measuring Instruments display shows 'COIN LOW', it means the datalogger time backup battery is low. This is part of the battery replacement kit and should be replaced with the main battery packs.
Explains safety symbols used in the manual for important safety information and warnings.
General safety warnings regarding PPE, confined spaces, and proper procedures.
Specifies minimum distances required before and after flow disturbances for accurate readings.
Details terminal block assignments and wire colors for different harnesses.
Details three methods for grounding the sensor, including preferred methods.
Explains the standard grounding method using grounding rings and earth ground.
Steps for connecting the converter to a computer and using the configuration software.
Details on changing settings like flow rate units, totalizer presets, and pulse outputs.
Lists common display messages and their corresponding troubleshooting steps.
Lists technical specifications for Ultra Mag flow meters, including pipe sizes, accuracy, and IP rating.
Provides further specifications like sensor submersibility depth, head loss, warranty, and pressure range.
Details physical, performance, and operational specifications for the ProComm GO converter.
Outlines the procedure for returning a unit for repair, including contact information and shipping instructions.
Explains the terms and conditions of the product warranty, including coverage and limitations.
General| Type | Electromagnetic Flow Meter |
|---|---|
| Flow Measurement | Volumetric flow rate |
| Flow Range | Up to 30 ft/s (9.1 m/s) |
| Output Signal | 4-20 mA, pulse |
| Power Supply | 110-240 VAC (optional) |
| Fluid Conductivity | 5 μS/cm minimum |
| Liner Materials | PTFE, Polyurethane |
| Electrode Materials | 316 Stainless Steel, Hastelloy C, Tantalum |
| Communication | HART, Modbus, Foundation Fieldbus |
| Enclosure | NEMA 4X (IP66) |
| Process Connections | Flanged |
| Materials | Carbon Steel, Stainless Steel |
