McCulloch 32CC TRIMMER - Detaching Trigger Housing and Spark Plug Removal

McCulloch 32cc Trimmer
6
3.10. The trigger housing can be pulled-free of the grip
after the trigger and rear housing are removed.
See Figure 3.10.
NOTE: The throttle cable and stop switch wires
are held in adjacent channels by a white plastic
sleeve that is inserted in the grip.
3.11. Pull the white sleeve out of the grip and unplug
the stop switch wires from their connections to
the contact strips in the trigger housing.
See Figure 3.11.
3.12. The grip and clutch housing can be separated
from the engine by removing the four screws
that fasten them together, using a T-25 driver.
See Figure 3.12.
3.13. Remove the grip and clutch housing, and unplug
the stop switch wires from their connections on
the engine. See Figure 3.13.
NOTE: Pay attention to the routing of the throttle
cable and stop switch wires.
3.14. Disconnect the H.T. lead from the spark plug.
and remove the spark plug using an 5/8”
wrench.
3.15. Pack the cylinder full of starter rope to act as a
piston stop.
Figure 3.10
Channel for
stop switch wires
Channel for
throttle cable
White plastic
sleeve
Figure 3.11
Remove
sleeve
Figure 3.12
Clutch housing
Stop switch wires
Starter
housing
NOTE:The grip is
integral with the
clutch housing
Figure 3.13
Channel for stop
switch wires
Channel for
throttle cable
