WHAT IS WHAT?
What is what on the brush cutter?
16
17
18
22
26
20
4
3
11
21
25
1
1
14
12
24
23
15
13
5
27
10
2
4
19
9
7
8
6
1
1 Blade
2 Grease filler cap, bevel gear
3 Bevel gear
4 Cutting attachment guard
5 Shaft
6 Start throttle button
7 Stop switch
8 Throttle trigger
9 Throttle lockout
10 Suspension ring
11 Cylinder cover
12 Starter handle
13 Fuel tank
14 Choke control
15 Air filter cover
16 Locking nut
17 Support flange
18 Support cup
19 Drive disc
20 Handlebar clamp
21 Operator
′
s manual
22 Transport guard
23 Socket spanner
24 Locking pin
25 Harness
26 Trimmer head
27 Air purge
