3
BATTERY
STARTER
12VDC
STARTER
M
A
AMMETER
(OPTIONAL)
FUSE
CARBURETOR SOLENOID
(IF SO EQUIPPED)
FUEL
LINE
IGNITION
UNIT
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
CLUTCH / BRAKE
(PEDAL UP)
SOLENOID
G
B
S
M
L
RED
RED
RED
BLUE RED
RED
GREEN
GREEN
WHITE
BLACK
BLACK
BLACK
BLAC
K
BLACK
BAGGER
INTERLOCK
(NO BAG,
CHUTE OR
PLUG)
BLACK
FBI
SWITCH
FBI BUZZER
BLACK
BLACK
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
87
87A
8586
30
RELAY
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
ATT'MENT CLUTCH
(CLUTCH OFF)
OPERATOR PRESENCE
RELAY
85 86
30
87
87A
BAGGER RELAY
85 86
30
87
87A
MOWER ENGAGED
RELAY
85 86
30
87
87A
SEAT SWITCH
(NOT OCCUPIED)
LIGHTING SYSTEM
OUTPUT
5 AMP AC @ 3600 RPM
ALTERNATOR
14 VOLTS AC MIN. @ 3600 RPM (LIGHTS OFF)
DIODE
28 VOLTS AC MIN. @ 3600 RPM
(CHARGING SYSTEM DISCONNECTED)
CHARGING SYSTEM OUTPUT
3 AMP DC @ 3600 RPM
IGNITION SWITCH
CIRCUITPOSITION
OFF
B+LON
B+S+LSTART
M+G
S
B
G
M
L
02639
TRACTOR- -MODEL NO. MC1292RB (96061001801), PRODUCT NO. 960 61 00-18
SCHEMATIC
