McCulloch MXC1640DK - Page 35

40cc Gas Chain Saw
6/16/2009
No. Parts No. Description Q P Code
1 9SGEB-05-20 SCREW 4 110
2 9SKKB-04-10 SCREW 7 110
3 9067-310802 CAP 1 110
4 9014-310803 GASKET 2 110
5
9292-310801F自
CYLINDER 1 110
6 9067-310801 CAP 1 110
7 9014-310801 GASKET 1 110
8 2 110
9 1 110
10 9CA-10.3 RING 2 110
11 9131-310801 WASHER 2 110
12 9NR-K101411 ROLLER 1 110
13 9PC-10-35-A PIN, PISTON 1 110
14 9157-332101 SEAL 1 110
15
9228-310819自
CRANKCASE ASS'Y 1 110
16 9DB-620101 BEARING 2 110
17 9228-310801-A CRANK/ROD ASS'Y 1 110
18 9014-310802 GASKET 1 110
19 9CB-32 RING 1 110
20 9157-310801 SEAL 1 110
21 9059-311001 BUSH 1 110
22 9191-310802 SCREW 2 110
23 9010-311002 WIRE 1 110
24 9NCC-05U NUT 2 110
25 9SKKB-05-14 SCREW 2 110
26A AO9014-310810-US888 KIT SPARK ARRESTOR INCL 26,27 1 110
26 9014-310810 COVER, MESH 1 110
27 9016-310801 SPARK ARRESTER 1 110
28 9228-311005T MUFFLER ASS'Y 1 110
MXC1840D
AO9290-310801-A-ZA999 PISTON & PISTON RING ASS'Y
PARTS LIST
29 9014-310804 GASKET 1 110
30 9191-310803 SCREW 2 110
31 9010-311003 WIRE 1 110
32 9SKKB-04-14 SCREW 6 110
33 9288-310801 IGNITION ASS'Y 1 110
34 9NHC-08 NUT 1 110
35 9169-310801 FLYWHEEL ASS'Y 1 110
36 6221-830301 WOODRUFF KEY 1 110
37 9014-310805 GASKET 1 110
38 9082-311001 ISOLATOR, CARBURETOR 1 110
39 9014-310006 GASKET 1 110
40 9013-311003 RUBBER PLUG 1 110
41 9228-311006 AIR GUIDE ASS'Y 1 110
42 9SKKB-04-70 SCREW 2 110
43 9183-311201 AIR FILTER 1 110
45 9SKKBB05-18 SCREW 16 110
46 9228-31P202 STARTER HOUSING ASS'Y, 021C ORANGE 1 110
46A 9194-310801 STARTAR ROPE 1 110
46B 9024-MD0701 STARTER SPRING EZ 1 110
46C 9137-MD0701 STARTER PULLEY 1 110
46D 9196-310702 HANDLE 1 110
46E 9228-310503 STARTER SPRING 1 110
46F 9137-31P201 STARTER PULLEY EZ 1 110
47 9211-311001 CAP, AIRWAY 1 110
48 9024-311001 SPRING 1 110
49 9191-311001 SCREW 4 110
50 9004-311001 BRACKET 1 110
51 9079-311002 BUSH 1 110
52 9WFB-10-18 SPACER 1 110
53 9228-310805 OIL PUMP ASS'Y 1 110
54 9129-311005 OIL HOSE 1 110
PARTS LIST
