WI NG FRAME, OUTSI DE
FOR 4045
Key Part No. Description Notes/ Revisions
1 BHY-5635 9/ 16 - 12 X 3 1/ 2 GRADE 8 BOLT
2 NLT-5612 9/ 16-12 TOP LOCK NUT
3 SPR-2712 HI NG PI N, 1 1/ 2 X 8 1/ 4
4 RD-4425 WI NG FOLD ARM, LEFT
5 NLT-1008 1” – 8 TOP LOCK NUT
6 BHY-1045 1” – 8 X 4 1/ 2 GRADE 8 HEX BOLT
7 RD-4426 WI NG FOLD ARM, RIGHT
8 HD-1149 CLEVIS PIN, 1x2-1/ 2
9 RD-4624 WI NG AXLE CYLINDER ARM
10 HYO-2008 RATCHET JACK, 8” STROKE
11 NLT-1008 1” – 8 TOP LOCK NUT
12 BHY-1033 1” – 8 X 3 1/ 4 GRADE 8 HEX BOLT
13 BHY-5635 9/ 16 - 12 X 3 1/ 2 GRADE 8 BOLT
14 NLT-5612 9/ 16-12 TOP LOCK NUT
15 WDL-2714 WI NG AXLE PI VOT PI N, 1 1/ 2 X 11 1/ 16
16 RD-4490 WI NG AXLE ASSEMBLY, DUAL
17 WDL-2505 WI NG AXLE SPI NDLE
18 HD-1371 6-HOLE HUB ASSEMBLY
19 HD-1368 RI M, 15X8, 6 BOLT, 2900 LB.
20 RD-4634
RD-4635
WI NG FRAME ASSEMBLY, LEFT OUTSI DE
WI NG FRAME ASSEMBLY, RIGHT OUTSI DE
To Next Page
