MLNX5 Digital Lock
User Manual
SYSTEM SPECIFICATION :
Connectivity Bluetooth 4.0, Wi-Fi (Wi-Fi Bridge required)
Identification Mode
TTLock App, Fingerprint, Card (Mifare 13.56 MHz), Code
and Bluetooth
User Capacity
120
Identification Time Instant recognition under 0.3 seconds
Code User-defined 4-8 digit
Keypad Backlight Yes
Temporary Code or Ekey Yes
Compatible Smartphone iOS7.0 or above, Android 4.4 or above
Remote Access Yes, Wi-Fi Gateway
Mechanical Key Override Yes
Micro-USB Backup Power
Interface
Yes
Working Voltage 6 V (4 X Alkaline AA Batteries)
Working Temperature
External Assembly: -4 °F ~ 149 °F (-20 °C ~ 65 °C)
Internal Assembly: 14 °F ~ 131 °F (-10 °C ~ 55 °C)
Battery Life Up to 12 months (10,000 times access)
Compatible Smart Home Eco-
system
Alexa and Google Assistant (Wi-Fi Gateway is required)
Hardware Type Lever
Door Thickness 38 - 55 mm
Door Handing Reversible (Left and Right)
8
Case Material Aluminium Alloy
IP Rating IP65
Finish Satin Nickel or Black
Warranty 12 Months
Available Mortice 60mm
Tubular Latch 60mm,70mm
Working Humidity 10%~95%
Factory Passcode 123456, after setting, factory passcode will be invalid
WiFi Gateway Available(Optional)
Unlock time 1-1.5 seconds
Dynamic current <200mA
Static current 45uA
