McIntosh C1100 Service Manual

C1100
REAR PANEL
3
P U SH
P U SH
P U SH
P U SH
P U SH
P U SH
P U SH P U SH P U SH
P U SH
P U SH P U SH
SERIAL
NUMBER
RIGHT OUTPUTS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION: RISQUE DE CHOC ELECTRIQUE-NE PA S OUVRIR
RIGHT INPUT
TO C1100 CONTROLLER
RIGHT OUTPUT
RIGHT BALANCED INPUTS RIGHT UNBALANCED INPUTS
GND GND
LEFT UNBALANCED INPUTS
LEFT INPUT
TO C1100 CONTROLLER
LEFT OUTPUT
LEFT BALANCED INPUTS LEFT OUTPUTS
McINTOSH LABORATORY, INC. BINGHAMTON, NY 13903
HANDCRAFTED IN USA WITH US AND IMPORTED PARTS
C1100 T UBE PREAMPLIFIER
2
1
MM
MAIN
REC/FIXED
3
1
24MC
1
2
4
3
6
5
MM
3
1
24MC
4
3
6
5
2
1
MAIN
REC/FIXED
1
2

McIntosh C1100 Specifications

General

Type	Preamplifier
Total Harmonic Distortion	0.005%
Frequency Response	20Hz to 20kHz +0, -0.5dB
Input Impedance	44K ohms
Output Impedance	200 ohms
Dimensions	Each chassis: 17-1/2" (44.45cm) width x 6" (15.24cm) height (including feet) x 18" (45.72cm) depth (including front panel and cables)
Rated Output Voltage	2.5V RMS
Phono Inputs	2 (MM/MC)
Balanced Outputs	2
Unbalanced Outputs	2
Maximum Voltage Gain	15dB
Gain	60dB (MC Phono); 40dB (MM Phono)
Inputs	High Level, Phono
Outputs	Balanced, Unbalanced
