McIntosh MCD301 Service Manual

MCD301
PARTS LIST con’t
33
MAIN PCB 750771 (cont’d)
Ref No. Description Part No.
Ref No. Description Part No.
R32 RES MF 8.25K 1% 1/4W 144549
R33 RES MF 8.25K 1% 1/4W 144549
R34 RES MF 1.5K 1% 1/4W 144539
R35 RES MF 332 OHM 1% 1/4W 144646
R36 RES MF 100K 1% 1/4W 144528
R37 RES MF 47.5K 1% 1/4W 144526
R38 RES MF 4.75M 1% 1/4W 144608
R39 RES MF 47.5K 1% 1/4W 144526
R40 RES MF 10K 1% 1/4W 144504
R41 RES MO 4.7 OHM 5% 1W 144656
R42 RES MO 4.7 OHM 5% 1W 144656
R43 RES MF 681 OHM 1% 1/4W 144567
R44 RES MF 1K 1% 1/4W 144513
R45 RES MF 475K 1% 1/4W 144604
R46 RES MF 4.75K 1% 1/4W 144520
R47 RES MF 47.5K 1% 1/4W 144526
R48 RES MF 47.5K 1% 1/4W 144526
R49 RES MF 1K 1% 1/4W 144513
R50 RES MF 22.1K 1% 1/4W 144564
R51 RES MF 22.1K 1% 1/4W 144564
R52 RES MF 562 OHM 1% 1/4W 144622
R53 RES MF 1.5K 1% 1/4W 144539
R54 RES MF 47.5 OHM 1% 1/4W 144642
R55 RES MF 47.5 OHM 1% 1/4W 144642
R56 RES MF 47.5 OHM 1% 1/4W 144642
R57 RES MF 22.1 OHM 1% 1/4W 144554
R58 RES MF 22.1 OHM 1% 1/4W 144554
R59 RES MF 22.1 OHM 1% 1/4W 144554
R60 RES MF 22.1 OHM 1% 1/4W 144554
R61 RES MF 47.5K 1% 1/4W 144526
R62 RES MF 22.1 OHM 1% 1/4W 144554
R63 RES MF 47.5 OHM 1% 1/4W 144642
R64 RES MF 47.5 OHM 1% 1/4W 144642
R65 RES MF 47.5 OHM 1% 1/4W 144642
R66 RES MF 47.5 OHM 1% 1/4W 144642
R67 RES MF 47.5 OHM 1% 1/4W 144642
R68 RES NETWORK 9 X 47K BUS 144673
R69 RES MF 22.1 OHM 1% 1/4W 144554
R70 RES MF 47.5 OHM 1% 1/4W 144642
R71 RES MF 22.1 OHM 1% 1/4W 144554
R72 RES MF 332 OHM 1% 1/4W 144646
R73 RES MF 10K 1% 1/4W 144504
R74 RES MF 2K 1% 1/4W 144517
R75 RES MF 47.5 OHM 1% 1/4W 144642
R76 RES MF 47.5 OHM 1% 1/4W 144642
R77 RES MF 10K 1% 1/4W 144504
R78 RES MF 150 OHM 1% 1/4W 144535
R79 RES MF 2.67K 1% 1/4W 144534
R80 RES MF 150 OHM 1% 1/4W 144535
R81 RES MF 2.67K 1% 1/4W 144534
R82 RES MF 150 OHM 1% 1/4W 144535
R83 RES MF 2.67K 1% 1/4W 144534
R84 RES MF 150 OHM 1% 1/4W 144535
R85 RES MF 2.67K 1% 1/4W 144534
R86 RES MF 365 OHM 1% 1/4W 144505
R87 RES MF 365 OHM 1% 1/4W 144505
R88 RES MF 365 OHM 1% 1/4W 144505
R89 RES MF 365 OHM 1% 1/4W 144505
R90 RES MF 11K 1% 1/4W 144523
R91 RES MF 365 OHM 1% 1/4W 144505
R92 RES MF 365 OHM 1% 1/4W 144505
R93 RES MF 365 OHM 1% 1/4W 144505
R94 RES MF 365 OHM 1% 1/4W 144505
R95 RES MF 2.21K 1% 1/4W 144584
R96 RES MF 2.55K 1% 1/4W 144734
R97 RES MF 2.21K 1% 1/4W 144584
R98 RES MF 2.21K 1% 1/4W 144584
R99 RES MF 2.21K 1% 1/4W 144584
R100 RES MF 2.94K 1% 1/4W 144667
R101 RES MF 100 OHM 1% 1/4W 144568
R102 RES MF 2.94K 1% 1/4W 144667
R103 RES MF 2.94K 1% 1/4W 144667
R104 RES MF 100 OHM 1% 1/4W 144568
R105 RES MF 2.94K 1% 1/4W 144667
R106 RES MF 2.21K 1% 1/4W 144584
R107 RES MF 2.21K 1% 1/4W 144584
R108 RES MF 2.21K 1% 1/4W 144584
R109 RES MF 2.21K 1% 1/4W 144584
R110 RES MF 2.67K 1% 1/4W 144534
R111 RES MF 2.67K 1% 1/4W 144534
R112 RES MF 2.67K 1% 1/4W 144534
R113 RES MF 2.67K 1% 1/4W 144534
R114 RES MF 2.67K 1% 1/4W 144534
R115 RES MF 2.67K 1% 1/4W 144534
R116 RES MF 2.67K 1% 1/4W 144534
R117 RES MF 2.67K 1% 1/4W 144534
R118 RES MF 1.33K 1% 1/4W 144619
R119 RES MF 1.33K 1% 1/4W 144619
R120 RES MF 1.33K 1% 1/4W 144619
R121 RES MF 1.33K 1% 1/4W 144619
R122 RES MF 5.62OHM 1% 1/4W 144556
R123 RES MF 5.62OHM 1% 1/4W 144556
R124 RES MF 47.5K 1% 1/4W 144526
R125 RES MF 47.5K 1% 1/4W 144526
R126 RES MF 47.5K 1% 1/4W 144526
R127 RES MF 47.5K 1% 1/4W 144526
R128 RES MF 47.5K 1% 1/4W 144526
R129 RES MF 47.5K 1% 1/4W 144526
R130 RES MF 499 OHM 1% 1/4W 144510
R131 RES MF 499 OHM 1% 1/4W 144510
R132 RES MF 499 OHM 1% 1/4W 144510
R133 RES MF 499 OHM 1% 1/4W 144510
R134 RES MF 499 OHM 1% 1/4W 144510
R135 RES MF 499 OHM 1% 1/4W 144510
R136 RES MF 100 OHM 1% 1/4W 144568
R137 RES MF 100 OHM 1% 1/4W 144568
R138 RES MF 100 OHM 1% 1/4W 144568
R139 RES MF 100 OHM 1% 1/4W 144568
R140 RES MF 100 OHM 1% 1/4W 144568
R141 RES MF 100 OHM 1% 1/4W 144568
R142 RES MF 1K 1% 1/4W 144513
R143 RES MF 1K 1% 1/4W 144513
R144 RES MF 1K 1% 1/4W 144513
R145 RES MF 1K 1% 1/4W 144513
R146 RES MF 1K 1% 1/4W 144513
R147 RES MF 1K 1% 1/4W 144513
R148 RES MF 2.67K 1% 1/4W 144534
R149 RES MF 2.67K 1% 1/4W 144534
R150 RES MF 2.67K 1% 1/4W 144534
R151 RES MF 2.67K 1% 1/4W 144534
R152 RES MF 1.33K 1% 1/4W 144619
R153 RES MF 1.33K 1% 1/4W 144619
R154 RES MF 1.33K 1% 1/4W 144619

McIntosh MCD301 Specifications

General

Frequency range	4 - 40000 Hz
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.002 %
CD-RW playback	Yes
Playback disc formats	CD audio, SACD
CD changer	No
Device type	Personal CD player
Product color	Black
Channels quantity	2 channels
Disc loading type	Tray
Number of optical discs	1 discs
Remote control type	IR

Weight and Dimensions

Depth	419.1 mm
Width	444.5 mm
Height	152.4 mm
Weight	12800 g
