McIntosh MCD301 Service Manual

MCD301
31
PARTS LIST
MAIN PCB 750771
Ref No. Description Part No.
C1 CAP MONO .1UF 50V 20% Z5U 061346
C2 CAP MONO .1UF 50V 20% Z5U 061346
C3 CAP MONO .1UF 50V 20% Z5U 061346
C4 CAP ELECT 47UF 35V 066446
C5 CAP MONO 150pF 5% 200V 061349
C6 CAP MONO .1UF 50V 20% Z5U 061346
C7 CAP ELECT 10UF 50V 066445
C8 CAP MPF 0.1UF 5% 63VDC 064325
C9 CAP ELECT 47UF 35V 066446
C10 CAP MONO 1000PF 50V 10% NPO 061344
C11 CAP MONO 1000PF 50V 10% NPO 061344
C12 CAP ELECT 47UF 35V 066446
C13 CAP MONO .1UF 50V 20% Z5U 061346
C14 CAP MONO .01UF 50V 20% 061345
C15 CAP DISC MONO .47UF 50V 061320
C16 CAP MONO 1000PF 50V 10% NPO 061344
C17 CAP MPF 1UF 5% 63VDC 064337
C18 CAP MONO .1UF 50V 20% Z5U 061346
C19 CAP DISC MONO .47UF 50V 061320
C20 CAP MONO .1UF 50V 20% Z5U 061346
C21 CAP MONO 1000PF 50V 10% NPO 061344
C22 CAP MONO .1UF 50V 20% Z5U 061346
C23 CAP MONO .1UF 50V 20% Z5U 061346
C24 CAP MONO .1UF 50V 20% Z5U 061346
C25 CAP ELECT 22UF 100V 066574
C26 CAP MONO 1000PF 50V 10% NPO 061344
C27 CAP MONO .1UF 50V 20% Z5U 061346
C28 CAP MPF 1UF 5% 63VDC 064337
C29 CAP ELECT 3300UF 35V 066509
C30 CAP MONO .1UF 50V 20% Z5U 061346
C31 CAP MONO .1UF 50V 20% Z5U 061346
C32 CAP ELECT 47UF 35V 066446
C33 CAP MONO 100PF 100V 10% NPO 061341
C34 CAP MONO .1UF 50V 20% Z5U 061346
C35 CAP MONO .1UF 50V 20% Z5U 061346
C36 CAP MONO .01UF 50V 20% 061345
C37 CAP ELECT 100UF 25V 066573
C38 CAP MONO .1UF 50V 20% Z5U 061346
C39 CAP ELECT 220UF 25V 066507
C40 CAP ELECT 220UF 25V 066507
C41 CAP MONO 100PF 100V 10% NPO 061341
C42 CAP ELECT 47UF 16V 066380
C43 CAP MONO .1UF 50V 20% Z5U 061346
C44 CAP MONO .1UF 50V 20% Z5U 061346
C45 CAP MONO .1UF 50V 20% Z5U 061346
C46 CAP ELECT 10UF 16V 066580
C47 CAP MONO .1UF 50V 20% Z5U 061346
C48 CAP MONO 100PF 100V 10% NPO 061341
C49 CAP MONO 100PF 100V 10% NPO 061341
C50 CAP MONO .1UF 50V 20% Z5U 061346
C51 CAP MONO .1UF 50V 20% Z5U 061346
C52 CAP MONO 100PF 100V 10% NPO 061341
C53 CAP ELECT 100UF 16V 5MM 066576
C54 CAP MONO .1UF 50V 20% Z5U 061346
C55 CAP MONO .1UF 50V 20% Z5U 061346
C56 CAP ELECT 10UF 16V 066580
C57 CAP ELECT 10UF 16V 066580
C58 CAP MONO .1UF 50V 20% Z5U 061346
C59 CAP MONO .1UF 50V 20% Z5U 061346
C60 CAP ELECT 47UF 16V 066380
C61 CAP ELECT 47UF 16V 066380
C62 CAP ELECT 10UF 16V 066580
C63 CAP MONO .1UF 50V 20% Z5U 061346
C64 CAP MONO 100PF 100V 10% NPO 061341
C65 CAP MONO 100PF 100V 10% NPO 061341
C66 CAP MPF 0.0022UF 5% 63VDC 064454
C67 CAP MPF 0.0022UF 5% 63VDC 064454
C68 CAP MPF 0.0022UF 5% 63VDC 064454
C69 CAP MPF 0.0022UF 5% 63VDC 064454
C70 CAP ELECT 470UF 16V 066508
C71 CAP ELECT 470UF 16V 066508
C72 CAP ELECT 470UF 16V 066508
C73 CAP ELECT 470UF 16V 066508
C74 CAP ELECT 47UF 16V 066380
C75 CAP MONO .1UF 50V 20% Z5U 061346
C76 CAP MPF 0.0033UF 5% 63VDC 064455
C77 CAP MPF 0.0033UF 5% 63VDC 064455
C78 CAP MPF 0.0033UF 5% 63VDC 064455
C79 CAP MPF 0.0033UF 5% 63VDC 064455
C80 CAP MONO 330PF 061332
C81 CAP MONO 330PF 061332
C82 CAP MONO 330PF 061332
C83 CAP MONO 330PF 061332
C84 CAP MPF 0.0022UF 5% 63VDC 064454
C85 CAP MPF 0.0022UF 5% 63VDC 064454
C86 CAP MPF 0.0022UF 5% 63VDC 064454
C87 CAP MPF 0.0022UF 5% 63VDC 064454
C88 CAP PF 0.001UF 5% 63VDC 064453
C89 CAP PF 0.001UF 5% 63VDC 064453
C90 CAP PF 0.001UF 5% 63VDC 064453
C91 CAP PF 0.001UF 5% 63VDC 064453
C92 CAP MONO .1UF 50V 20% Z5U 061346
C93 CAP MONO .1UF 50V 20% Z5U 061346
C94 CAP ELECT 10UF 50V 066445
C95 CAP ELECT 10UF 50V 066445
C96 CAP ELECT 47UF 16V 066380
C97 CAP ELECT 47UF 16V 066380
C98 CAP ELECT 47UF 16V 066380
C99 CAP ELECT 47UF 16V 066380
C100 CAP ELECT 47UF 16V 066380
C101 CAP ELECT 47UF 16V 066380
C102 CAP ELECT 47UF 16V 066380
C103 CAP ELECT 47UF 16V 066380
C104 CAP ELECT 47UF 16V 066380
C105 CAP ELECT 47UF 16V 066380
C106 CAP ELECT 47UF 16V 066380
C107 CAP ELECT 47UF 16V 066380
C108 CAP MONO .1UF 50V 20% Z5U 061346
C109 CAP MONO .1UF 50V 20% Z5U 061346
C110 CAP MONO .1UF 50V 20% Z5U 061346
C111 CAP MONO .1UF 50V 20% Z5U 061346
C112 CAP MPF 0.0022UF 5% 63VDC 064454
C113 CAP MPF 0.0022UF 5% 63VDC 064454
C114 CAP MPF 0.0022UF 5% 63VDC 064454
C115 CAP MPF 0.0022UF 5% 63VDC 064454
C116 CAP ELECT 22UF 100V 066574
C117 CAP ELECT 22UF 100V 066574
C118 CAP ELECT 10UF 16V 066580
C119 CAP MONO .1UF 50V 20% Z5U 061346
C120 CAP ELECT 10UF 16V 066580
C121 CAP MONO .1UF 50V 20% Z5U 061346
C122 CAP MONO .1UF 50V 20% Z5U 061346
C123 CAP ELECT 10UF 16V 066580
C124 CAP ELECT 22UF 100V 066574
2
Ref No. Description Part No.

McIntosh MCD301 Specifications

General

Frequency range	4 - 40000 Hz
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.002 %
CD-RW playback	Yes
Playback disc formats	CD audio, SACD
CD changer	No
Device type	Personal CD player
Product color	Black
Channels quantity	2 channels
Disc loading type	Tray
Number of optical discs	1 discs
Remote control type	IR

Weight and Dimensions

Depth	419.1 mm
Width	444.5 mm
Height	152.4 mm
Weight	12800 g
