MCD301
1. The heavy notes on the schematic denote the primary
signal path.
2. Unless otherwise noted, all voltages indicated on the
schematics are measured under the following conditions:
a. AC input at 120 volts, 50/60Hz.
b. All voltages are +/-10% with respect to ground. A
high impedance (10 megaohm) voltmeter must be used.
3. Unlessotherwisespecied:
a. Resistor values are in ohms.
b. Capacitor values are microfarads (uF).
c. Inductor values are in microhenries (uH).
4. On PC board drawings, Square pad indicates:
a. Polarized Capacitors - Positive
b. Diodes - Cathode
c. Others - Pin 1
5. WARNING
Parts marked with the symbol have critical
characteristics. Use only replacement parts recom-
mended by the manufacturer.
6. Use McIntosh Remote Control Model HR056 with the
MCD301.
NOTES
SAFETY INFORMATION
CAUTION: Invisible Laser Radiation when open.
DO NOT stare into the beam or view
directly with optical instruments. Use of
controls or adjustments or performance
of procedures other than those speci-
edintheOwnersManualmayresult
in Hazardous Radiation Exposure.
Servicing of laser mechanism is to be
performed at the service facility at
McIntosh Laboratory Inc.
This product incorporates an embedded
Class 3R Laser (IEC60825-1).
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
VAROITUS! Laitteen kayttaminen muulla kuin
tassa kayttoohjeessa mainitulla
tavalla saattaa altistaa kayttajan
turvallisuusluokan 1 ylittavalle
nakymattomalle lasersateiiylle.
VARNING! Om apparaten anvands pa annat
satt an i denna bruksanvisning
specicerats,kananvandaren
utsattas for osynbg laserstraining,
som overskrider gransen for
laserklass 1.
3
