MCD550
Ref. No. Description Part No.
POWER PCB 751547 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
5
43
F2 FUSE 2A 250V SLO-BLO 5X20 IEC 089123
F3 FUSE 0.5A SLO-BLO 5X20 IEC 089126
F4 FUSE 0.5A SLO-BLO 5X20 IEC 089126
F5 FUSE 1A 250V SB 5X20 ULCSA IEC 089132
FH2 HOLDER FUSE 5X20 PCB MOUNT 178159
FH3 HOLDER FUSE 5X20 PCB MOUNT 178159
FH4 HOLDER FUSE 5X20 PCB MOUNT 178159
FH5 HOLDER FUSE 5X20 PCB MOUNT 178159
HS1 HEATSINK TO220 080021
HS2 HEATSINK TO220 080021
J1 10 PIN SHROUDED HEADER 2MM 117973
J2 HEADER 9 CIRCUIT POST NATURAL 117724
J3 10 PIN SHROUDED HEADER 2MM 117973
J4 10 PIN SHROUDED HEADER 2MM 117973
J5 10 PIN SHROUDED HEADER 2MM 117973
J6 7PIN SHROUDED HEADER 117910
L2 INDUCTOR 15uH 20% SMD 122450
L3 INDUCTOR 27uH 20% SMD 122451
L4 FERRITE 60 OHM 5 AMP SMD 076025
L5 FERRITE 60 OHM 5 AMP SMD 076025
PCB1 PC BD POWER 130199
Q1 TRANSISTOR PNP 60V MMBTA55LT1G 132334
Q2 TRANSISTOR PNP 50V 2SA2153 132340
Q3 TRANSISTOR NPN 60V MMBTA05LT1G SMD 132333
Q4 TRANSISTOR NPN 60V MMBTA05LT1G SMD 132333
R1 FUSE RESETTABLE 900mA 144733
R2 RES MF 2.21 OHM 1% 1/4W 144607
R3 RES MF 2.74K 1% 1/4W 144587
R5 RES MF 10K 1% 1/4W 144504
R6 RES SMD0805 10K 1/8W 1% 145010
R7 RES MF 2.74K 1% 1/4W 144587
R8 RES SMD0805 3.32K 1/8W 1% 145026
R9 RES SMD0805 3.92K 1/8W 1% 145027
R10 RES SMD0805 18.2K 1/8W 1% 145031
R11 RES SMD0805 5.62K 1/8W 1% 145028
R12 RES MF 1.21K 1% 1/4W 144566
R13 RES SMD0805 4.75K 1/8W 1% 145008
R14 RES SMD0805 18.2K 1/8W 1% 145031
R15 RES SMD0805 100K 1/8W 1% 145014
R16 RES SMD0805 100K 1/8W 1% 145014
R17 RES MF 2.74K 1% 1/4W 144587
R18 RES SMD0805 47.5K 1/8W 1% 145013
R19 RES MF 2.74K 1% 1/4W 144587
R20 RES MF 10K 1% 1/4W 144504
R21 RES SMD0805 15K 1/8W 1% 145011
R22 RES SMD0805 475 1/8W 1% 145020
R23 RES SMD0805 1K 1/8W 1% 145007
R24 RES SMD0805 6.81K 1/8W 1% 145029
R25 RES SMD0805 1K 1/8W 1% 145007
R26 RES SMD0805 10K 1/8W 1% 145010
R27 RES MF 249 OHM 1% 1/4W 144721
R28 RES MF 249 OHM 1% 1/4W 144721
R29 RES SMD0805 10K 1/8W 1% 145010
R30 RES SMD0805 1.5K 1/8W 1% 145022
R31 RES SMD0805 150 1/8W 1% 145019
R32 RES SMD0805 1K 1/8W 1% 145007
R33 RES SMD0805 100 1/8W 1% 145005
R34 RES SMD0805 475 1/8W 1% 145020
R35 RES SMD0805 10K 1/8W 1% 145010
R36 RES SMD0805 2.74K 1/8W 1% 145025
R37 RES SMD0805 1.21K 1/8W 1% 145021
R38 RES SMD0805 10K 1/8W 1% 145010
R39 RES SMD0805 10K 1/8W 1% 145010
R40 RES SMD0805 100K 1/8W 1% 145014
R41 RES SMD0805 100K 1/8W 1% 145014
U1 IC REGULATOR 5V 500mA SMD 133737
U3 REG VAR 1.24-26 1A SMD 133717
U4 IC SWITCHING REGULATOR 3A SMD 133799
U5 IC SWITCHING REGULATOR 3A SMD 133799
U6 IC SINGLE 2-INPUT AND GATE SMD 133502
U7 REG VAR 1.24-26 1A SMD 133717
U8 REG NEG ADJ 1A ENA SMD 133731
U9 REG NEG ADJ 1A ENA SMD 133731
U10 IC SINGLE 2 INPUT EX OR GATE SMD 133837
ASSY SMD POWER 710191
6
BACKUP PS PCB 751548
D38 DIODE ZENER 8.2V 1/2W 070130
C55 CAP MPF 0.033UF 100V 10% 064427
C56 CAP ELECT 2200UF 25V 20% LOW ESR 066612
C57 CAP ELECT 2200UF 25V 20% LOW ESR 066612
C58 CAP MONO .1UF 50V 20% SMD0805 061365
C59 CAP ELECT 1UF 50V SMD 066600
C60 CAP NPO 1000PF 100V 5% SMD0805 061391
C61 CAP ELECT 100UF 25V SMD 066605
D30 DIODE SMALL SIGNAL 4148 SMD 070199
D31 DIODE RECTIFIER 400V 1A SMD 070208
D32 DIODE RECTIFIER 400V 1A SMD 070208
D33 DIODE SCHOTTKY 40V 2A SMD 070210
D34 DIODE SCHOTTKY 40V 2A SMD 070210
D35 DIODE SCHOTTKY 40V 2A SMD 070210
D36 DIODE SCHOTTKY 40V 2A SMD 070210
D37 DIODE SCHOTTKY 40V 2A SMD 070210
D39 DIODE RECTIFIER 400V 1A SMD 070208
D40 DIODE RECTIFIER 400V 1A SMD 070208
FH1 HOLDER FUSE 5X20 PCB MOUNT 178159
J6 CONNECTOR 2PIN HEADER 11.88MM 118026
J7 CONN PCB MOUNT POWER RED 117719
J8 CONN PCB MOUNT POWER RED 117719
J9 CONN PCB MOUNT POWER RED 117719
J10 7PIN SHROUDED HEADER 117910
K1 RELAY POWER TV5 12V 087086
L6 FERRITE 600 OHM 0.5 AMP SMD 076026
PCB1 PC BD BACKUP 130200
Q8 TRANSISTOR NPN 60V SMD 132333
Q9 TRANSISTOR NPN 60V SMD 132333
Q10 TRANSISTOR NPN 60V SMD 132333
Q11 TRANSISTOR NPN 60V SMD 132333
R45 RES POLYSWITCH RXE030 144670
R46 RES POLYSWITCH RXE030 144670
R47 RES SMD0805 22.1K 1/8W 1% 145012
R48 RES SMD0805 1.82K 1/8W 1% 145023
R49 RES SMD0805 100K 1/8W 1% 145014
R50 RES SMD0805 100K 1/8W 1% 145014
R51 RES SMD0805 10K 1/8W 1% 145010
R52 RES SMD0805 100 1/8W 1% 145005
R53 RES SMD0805 8.25K 1/8W 1% 145009
R54 RES SMD0805 10K 1/8W 1% 145010
