McIntosh MCD550 - Page 28

Ref. No. Description Part No.
BACKUP PS PCB 751548 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
6
44
R55 RES SMD0805 100K 1/8W 1% 145014
R56 RES SMD0805 100K 1/8W 1% 145014
T1 TRANSFORMER BACKUP 159376
U15 IC REGULATOR 3.3V 500mA SMD 133736
7
CONNECTOR PCB 751567
J1 CONNECTOR 2MM 5 PIN RA 118032
J2 HEADER 6PIN RA 2MM 118090
J3 HEADER 2MM 7PIN R-ANGLE 117941
PCB1 PC BD CONNECTOR 130207
R1 RES SMD0805 0 1/8W 0% 145016
R2 RES SMD0805 0 1/8W 0% 145016
R3 RES SMD0805 0 1/8W 0% 145016
R4 RES SMD0805 0 1/8W 0% 145016
C1 CAP MONO .1UF 50V 20% SMD0805 061365
(C1) GROMMET 078031
C2 CAP MONO .1UF 50V 20% SMD0805 061365
(C2) GROMMET 078031
GP1 SOLDER LUG 075086
J1 HEADPHONE JACK 1/4” 117881
J2 CONN 4 PIN RIGHT ANGLE 117240
PCB1 PC BD HEADPHONE 130173
ASSY SMD HEADPHONE 710171
R5 RES SMD0805 10K 1/8W 1% 145010
R6 RES SMD0805 10K 1/8W 1% 145010
R7 RES SMD0805 10K 1/8W 1% 145010
8
HEADPHONE PCB 751451
