McIntosh MCLK12

14
Specifications
Specifications
Time Base
Temperature compensated quartz crystal oscillator
Time Base Accuracy
±2 parts per million from 0°C to +40°C
Clock Time Display
Dynamic magnetic meters
Backup Battery Type
Approved Lithium Batteries
Brand IEC No. ANSI/NEDA No.
Energizer CR2032
1
5004LC
1
Panasonic CR2032(PA/1B)
1
5004LC
1
Power Control Input and Output
5-15VDC, 50mA maximum
Power Requirements
100V ~ 50/60Hz at 2.0 Watts
110V ~ 50/60Hz at 2.0 Watts
120V ~ 50/60Hz at 2.0 Watts
220V ~ 50/60Hz at 2.0 Watts
230V ~ 50/60Hz at 2.0 Watts
240V ~ 50/60Hz at 2.0 Watts
Note: Refer to the rear panel of the MCLK12 for the cor-
rect voltage.
System Overall Dimensions
Width is 17-1/2 inches (44.45cm)
Height is 8-7/8 inches (22.54cm)
Depth is 5 inches (52.54 cm) with AC Cord connected
System Weight
8 pounds (3.62 Kg) net, 10 pounds (4.54 Kg) in ship-
ping carton
System Shipping Carton Dimensions
Width is 22-3/4 inches (57.8cm)
Depth is 13-1/4 inches (33.7cm)
Height is 7-1/2 inches (19.1cm)
