14
Technical Specifications
Amplier
Power Output
50 watts into 8 ohm loads
80 watts into 4 ohm loads
Output Load Impedance
8 ohms or 4 ohms
Rated Power Band
20Hz to 20kHz
Total Harmonic Distortion
0.2% maximum harmonic distortion at any level
from 250 milliwatts to one-half of rated power
output, 20Hz to 20kHz
0.5% maximum harmonic distortion at any level
from one-half to full rated power output, 20Hz to
20kHz
Dynamic Headroom
1dB 8 ohm load
1.3dB 4 ohm load
Frequency Response
+0, -0.7dB from 20Hz to 20kHz
Input Sensitivity (for rated output)
1.5V PWR Amplier IN
A-Weighted Signal to Noise Ratio
93dB (110dB below rated output) PWR Amplier
IN
Intermodulation Distortion
0.1% maximum if instantaneous peak power
output does not exceed the rated output for any
combination of frequencies from 20Hz to 20kHz
Wide Damping Factor
Greater than 200, 8 ohm load
Greater than 100, 4 ohm load
Input Impedance
6.5K ohms
Voltage gain
22dB
Preamplier
Frequency Response
+0, -0.7dB from 20Hz to 20,000Hz
Total Harmonic Distortion
0.2% from 20Hz to 20,000Hz
Rated Output (Main)
1.5V
Maximum Voltage Output
9V RMS
Sensitivity (for rated output)
High Level, 300mV AUX Input
Signal To Noise Ratio (A-Weighted)
High Level, 90dB
Phono, 75dB
Input Impedance
68K ohms AUX Input
Maximum Input Signal
4V AUX Input
Phono MM, 45mV
Voltage Gain
AUX Input to Main Output: 14dB
Phono MM Section: 40dB
Output Impedance
100 ohms
Headphone Load Impedance
100 ohms to 600 ohms
Digital Input Sample Rates
Optical: 16Bit, 24Bit - 32kHz to 192kHz
Coaxial: 16Bit, 24Bit - 32kHz to 192kHz
Bluetooth Proles
A2DP, AVRCP, SBC, HD
TRIGGER OUTPUT
12VDC, 50mA maximum
Olympia Cartridge
Cartridge Type
Moving Magnet (MM)
Frequency Response
12Hz-30kHz
Output Voltage/Channel
4mV @ 1kHz
Channel Separation
30dB @ 1kHz
Channel Balance
1.5dB/1kHz
Compliance
12x10-6 cm/dyn @ 100Hz
Stylus Size/Shape
.3x.7/Elliptical
Load Impedance
47k Ohms
Tracking Force Range
1.8-2.2 grams
Recommended Force
2.0 grams
Cartridge Weight
6.5 grams
