McIntosh XCS2K - Rear Panel Connections

11
3 2 1 3 2 1
3 2 1
Installation, con’t and Rear Panel Connections
HIGH Frequency Input Con-
nections 1, 2, and 3 for a 8 ohm
Loudspeaker.
Note: 1, 2 and 3 Terminals (+)
are internally connected
together; 1, 2 and 3 Termi-
nals (-) are also internally
connected together.
MIDrange Frequency Input Con-
nections 1, 2, and 3 for a 8 ohm
Loudspeaker.
Note: 1, 2 and 3 Terminals (+)
are internally connected
together; 1, 2 and 3 Termi-
nals (-) are also internally
connected together.
LOW Frequency Input Con-
nections 1, 2, and 3 for a 8 ohm
Loudspeaker.
Note: 1, 2 and 3 Terminals (+)
are internally connected
together; 1, 2 and 3 Termi-
nals (-) are also internally
connected together.
3 2 1 3 2 1 3 2 1
