5.8.2 Re-fitting into enclosure
• Referring to the illustration, place the EPIRB
on its side in the enclosure. As illustrated, the
TEST button is furthest from the back of the
enclosure.
• Engage base of EPIRB into the recess in the
lever arm.
• Push the EPIRB into the enclosure to engage
the retaining clip.
• Bend the antenna as shown and retain it in the
recess.
• Refit cover squarely, engaging the guides at
the top end and the rod through hole in cover.
• Locate cover onto backplate, then snap down
over locating lug. Check that the cover is
correctly located (see following page).
• Refit R-clip through hole in end of release rod.
CAUTION
Failure to fit EPIRB
correctly may impair
its ability to float free
in an emergency
