2.3 HORIZONTAL SYSTEM
Sweep Time
0.1S / DIV ~0.1µS / DIV ±3%
Trimming Ratio
≧2.5:1
2.4 X-Y MODE
Sensitivity
0.2V/DIV～0.5V/DIV
Bandwidth(-3dB) DC: 0~1MHz AC: 10Hz~1MHz
2.5 CALIBRATION SIGNAL
Waveform Symmetric Square Wave
Range
05.V ±2%
Frequency
1kHz ±2%
2.6 CRT
Display Area
8 × 10DIV 1DIV=6mm
Accelerating Voltage 1200V
Display Color Green
2.7 POWER SOURCE
Voltage Range
110V ±10%
Frequency
60Hz ±2Hz
Power Consumption 25W
2.8 PHYSICAL FEATURES
Weight 3kg
Dimensions (H x W x D)
190 ×130 ×270mm
2.9 WORKING ENVIRONMENT
Working temperature
5°C ~ 40°C
Storage Environment -30°C ~60°C, 10~80%RH
Working Altitude
≤2000m
2.10 PRESSURE-PROOF TEST
Pressure-proof test 1500V 1min
