- 18 -
Table 8. Capacitance
Range Resolution Accuracy Remarks
1nF 1pF ±(5.0% rdg+50)
Overload protection: 250V RMS
10nF 10pF
±(2.5% rdg+50)
100nF 100pF
1μF 1nF
10μF 10nF
100μF 100nF
Table 9. Diode
Range Accuracy Resolution Remarks
3.0000V ±(3.0% rdg+5) 0.0001V
Diode positive voltage drop
Overload protection: 250V RMS
Table 10. Square Wave Output
Description
Voltage amplitude Approx.3V
Frequency 0.5Hz~5000Hz
Duty cycle 1%~99%
Table 11. Temperature
Range Accuracy Resolution Remarks
-50℃~1300℃
±(1.5% rdg+10)
0.1℃
K type thermocouple
Overload protection: 250V RMS
-58℉~2372℉ 0.1℉
6.2 General Specifications
Max.voltage between terminal and ground: 1000V RMS
Continuity beeper: Approx.3kHz
Display: dual display 80000, update 4 times/Sec.
Bar graph: 23 segments, update 40 times/Sec.
Electromagnetic compatibility:
For all ranges and functions (except capacitance), in a RF field of 1V/m, total accuracy=specified
accuracy+5% of range.
In a RF field, the capacitance has no specified range.
For all ranges and functions, in a RF field above 1V/m, there is no specified range.
Safety/Compliance: IEC 61010 CAT II 1000V, and CAT III 600V
Input voltage: AC110V/220V selectable, 50/60Hz
Operating environment: temperature 0℃~50℃, altitude below 2000m
Storage environment: temperature -20℃~60℃, altitude below 5000m
Relative humidity: ≤75%, at 0℃~40℃; ≤45%, at 40℃~50℃
Dimension: 260x220x82mm
Weight: Approx.1.4KG
Accessories:
Manual: 1pc
Test lead: 1pc
K type thermocouple: 1pc
RS232 package: 1set
