McQuay ACZ 028A User Manual

IOMM ACZ1 ACZ 010A through 039A
19
Table 7, ACZ 010A – 039A Field Wiring Data, Single Point Power
Wiring to
Standard Power Block Terminal
Wiring to
Optional Disconnect Switch
ACZ
UNIT
SIZE
Volts HZ.
Maximum
Terminal Amps
Connector Wire Range
(Copper Wire Only)
Disconnect
Size
Connector Wire
Range
(Copper Wire Only)
208 175 14 GA – 2/0 100 8 GA – 2/0
230 175 14 GA – 2/0 100 8 GA – 2/0
460 175 14 GA – 2/0 45 14 GA – 4 GA
010A
575
60
175 14 GA – 2/0 63 14 GA – 1 GA
208 175 14 GA – 2/0 100 8 GA – 2/0
230 175 14 GA – 2/0 100 8 GA – 2/0
460 175 14 GA – 2/0 45 14 GA – 4 GA
013A
575
60
175 14 GA – 2/0 63 14 GA – 1 GA
208 175 14 GA – 2/0 100 8 GA – 2/0
230 175 14 GA – 2/0 100 8 GA – 2/0
460 175 14 GA – 2/0 45 14 GA – 4 GA
016A
575
60
175 14 GA – 2/0 63 14 GA – 1 GA
208 175 14 GA – 2/0 175 6GA – 300 kcmil
230 175 14 GA – 2/0 175 6GA – 300 kcmil
460 175 14 GA – 2/0 45 14 GA – 4 GA
020A
575
60
175 14 GA – 2/0 63 14 GA – 1 GA
208 175 14 GA – 2/0 200 6GA – 300 kcmil
230 175 14 GA – 2/0 200 6GA – 300 kcmil
460 175 14 GA – 2/0 100 8 GA – 2/0
025E
575
60
175 14 GA – 2/0 160 8 GA – 1/0
208 175 14 GA – 2/0 200 6GA – 300 kcmil
230 175 14 GA – 2/0 200 6GA – 300 kcmil
460 175 14 GA – 2/0 100 8 GA – 2/0
028A
575
60
175 14 GA – 2/0 160 8 GA – 1/0
208 175 14 GA – 2/0 200 6GA – 300 kcmil
230 175 14 GA – 2/0 200 6GA – 300 kcmil
460 175 14 GA – 2/0 100 8 GA – 2/0
033E
575
60
175 14 GA – 2/0 160 8 GA – 1/0
208 335 6 GA – 400 kcmil 200 6GA – 300 kcmil
230 335 6 GA – 400 kcmil 200 6GA – 300 kcmil
460 175 14 GA – 2/0 175 6GA – 300 kcmil
039A
575
60
175 14 GA – 2/0 175 6GA – 300 kcmil
See page 20 for all Electrical Data notes.
