OM AGSD-1 23
Description Default Range PW
Start Reset Delta T
10 F 0 to 20 F
M
Soft Load
Off Off, On M
Begin Capacity Limit 40% 20-100% M
Soft Load Ramp 20 min 1-60 minutes M
Demand Limit Off Off, On M
# of Circuits 2 2-4 O
Low Ambient Lockout
55 F 0(35) to 70 F
M
Ice Time Delay 12 1-23 hours M
Clear Ice Timer No No,Yes M
SSS Communication No No, Yes M
PVM Multi Point
Single Point, Multi Point ,
None(SSS)
O
BAS Protocol Modbus BACnet, LonWorks, Modbus M
Ident number 1 0-200 M
Baud Rate 19200 1200,2400,4800,9600,19200 M
Evap LWT sensor offset 0 -5.0 to 5.0 deg M
Evap EWT sensor offset 0 -5.0 to 5.0 deg M
OAT sensor offset 0 -5.0 to 5.0 deg M
Compressors-Global
Start-start timer 20 min 15-60 minutes M
Stop-start timer 5 min 3-20 minutes M
Pumpdown Pressure
25 psi 10 to 40 psi M
Pumpdown Time Limit
120 sec 0 to 180 sec M
Light Load Stg Dn Point
25% 20 to 50% M
Stage Up Delay
5 min 0 to 60 min M
Max # Comps Running 3 1-3 M
Sequence # Cir 1 1 1-3 M
Sequence # Cir 2 1 1-3 M
Sequence # Cir 3 1 1-3 M
Alarm Limits
Low Evap Pressure-Unload 28 psi 0(26) to 45 psi M
Low Evap Pressure-Hold 30 psi 0(28) to 45 psi M
Oil Press Delay
30 sec 10-180 sec M
Oil Press Differential
25 psi 0-60 psi M
High Discharge Temperature
220 F
150 to 230 F M
High Lift Pressure Delay 5 sec 0 to 30 sec M
Evaporator Water Freeze
36 F 15(36) to 42 F
M
Evaporator Flow Proof
3 sec 3 to 10 sec M
Low OAT Start Timer
60 sec 20 to 90 sec M
The following setpoints exist individually for each circuit:
Description Default Range PW
Compressor
Circuit mode enable Disable, enable, test M
Slide control auto Auto, manual M
Slide position 0 0-100 M
Compressor Size 205 205, 220, 235 M
Clear Cycle Timers
No No, yes M
Maximum Slide Target 100.0 0-100.0% M
EXV control Auto Auto, manual M
EXV position 0 0-6386 M
Service Pumpdown No No,Yes M
Slide min pos offset 0 -15 to 15% M
Slide max pos offset 0 -15 to 15% M
Continued on next page.
