IOMM AGZ-5 AGZ 026B through 130B 35
Table 21, AGZ 026 BM/BS – 070BM/BS, Field Wiring, Single Point
Wiring to Standard
Power Block
Wiring to Optional
Non-Fused Disconnect Switch
AGZ
Unit
Size
Volts
Terminal
Amps
Connector Wire
Range
(Copper Wire Only)
Disconnect
Size
Connector Wire
Range
(Copper Wire Only)
208 175 14 GA – 2/0 225 # 4 - 300 kcmil
230 175 14 GA – 2/0 225 # 4 - 300 kcmil
380 175 14 GA – 2/0 150 # 4 - 300 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
026B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 225 # 4 - 300 kcmil
230 380 #4 – 500kcmil 225 # 4 - 300 kcmil
380 175 14 GA – 2/0 150 # 4 - 300 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
030B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 225 # 4 - 300 kcmil
230 380 #4 – 500kcmil 225 # 4 - 300 kcmil
380 175 14 GA – 2/0 150 # 4 - 300 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
035B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 225 # 4 - 300 kcmil
230 380 #4 – 500kcmil 225 # 4 - 300 kcmil
380 175 14 GA – 2/0 150 # 4 - 300 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
040B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 225 # 4 - 300 kcmil
230 380 #4 – 500kcmil 225 # 4 - 300 kcmil
380 175 14 GA – 2/0 150 # 4 - 300 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
045B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 250 #6 - 350 kcmil
230 380 #4 – 500kcmil 250 #6 - 350 kcmil
380 175 14 GA – 2/0 150 # 4 - 300 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
050B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
230 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
380 175 14 GA – 2/0 250 #6 - 350 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
055B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
230 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 250 #6 - 350 kcmil
460 175 14 GA – 2/0 150 # 4 - 300 kcmil
060B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
230 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 250 #6 - 350 kcmil
460 175 14 GA – 2/0 250 # 4 - 300 kcmil
065B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
208 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
230 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 250 #6 - 350 kcmil
460 380 #4 – 500kcmil 250 # 4 - 300 kcmil
070B
575 175 14 GA – 2/0 150 # 4 - 300 kcmil
All Electrical Data notes are on page 49.
