38 AGZ 026B through 130B IOMM AGZ-5
Table 24, AGZ 075BM/BS - 130BM/BS, Field Wiring, Single Point
Wiring to Standard
Power Block
Wiring to Optional
Non-Fused Disconnect Switch
AGZ
Unit
Size
Volts
Terminal
Amps
Connector Wire
Range
(Copper Wire Only)
Disconnect
Size
Connector Wire Range
(Copper Wire Only)
208 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 250 #6 - 350 kcmil
460 380 #4 – 500kcmil 250 #6 - 350 kcmil
075B
575 380 #4 – 500kcmil 250 #6 - 350 kcmil
208 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
460 380 #4 – 500kcmil 250 #6 - 350 kcmil
085B
575 380 #4 – 500kcmil 250 #6 - 350 kcmil
208 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
460 380 #4 – 500kcmil 250 #6 - 350 kcmil
090B
575 380 #4 – 500kcmil 250 #6 - 350 kcmil
208 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 600 (2) 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
460 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
100B
575 380 #4 – 500kcmil 250 #6 - 350 kcmil
208 760 2 GA – 500kcmil 800 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 800 (2) 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
460 380 #4 – 500kcmil 400 (2) 3/0-250 kcmil
110B
575 380 #4 – 500kcmil 400 (2) 3/0-250 kcmil
208 760 2 GA – 500kcmil 800 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 800 (2) 250 kcmil -500 kcmil
380 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
460 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
120B
575 380 #4 – 500kcmil 400 (2) 3/0-250 kcmil
208 760 2 GA – 500kcmil 800 (2) 250 kcmil -500 kcmil
230 760 2 GA – 500kcmil 800 (2) 250 kcmil -500 kcmil
380 760 2 GA – 500kcmil 600 (2) 3/0-250 kcmil
460 380 #4 – 500kcmil 400 250 kcmil -500 kcmil
130B
575 380 #4 – 500kcmil 400 (2) 3/0-250 kcmil
All Electrical Data notes are on page 49.
