IOMM AGZ-5 AGZ 026B through 130B 13
Table 2, AGZ-BS, Isolator Loads At Each Mounting Location (With Aluminum Fins)
1 2 3 4 5 6 Total Unit
(1) Copper
Fin Add
Unit
Size
No.
of
Fans
lb kg lb kg lb kg lb kg lb kg lb kg lb kg lb. kg
026B 4 1281 580 941 426 1020 462 748 339 - - - - 3990 1807 72 32
030B 4 1297 588 952 431 1032 467 759 344 - - - - 4040 1830 72 32
035B 4 1283 581 942 427 1069 484 786 356 - - - - 4080 1848 72 32
040B 4 1360 616 940 426 1082 490 748 339 - - - - 4130 1871 72 32
045B 4 1377 624 952 431 1148 520 793 359 - - - - 4270 1934 72 32
050B 4 1384 627 1016 460 1153 522 847 384 - - - - 4400 1993 119 54
055B 4 1391 630 1085 492 1159 525 905 410 - - - - 4540 2057 119 54
060B 4 1410 639 1099 498 1175 532 916 415 - - - - 4600 2084 142 65
065B 4 1382 626 1214 550 1205 546 1059 480 - - - - 4860 2202 142 65
070B 4 1419 643 1246 564 1238 561 1087 492 - - - - 4990 2260 217 99
075B 6 1854 840 1411 639 1854 840 1411 639 - - - - 6530 2958 217 99
085B 6 1942 880 1479 670 1856 841 1413 640 - - - - 6690 3031 217 99
090B 6 1975 895 1450 657 1975 895 1450 657 - - - - 6850 3103 217 99
100B 8 1464 663 1341 607 1219 552 1400 634 1282 581 1164 527 7870 3565 289 131
110B 8 1513 685 1358 615 1204 545 1513 685 1358 615 1204 545 8150 3692 289 131
120B 8 1656 750 1486 673 1317 597 1582 717 1420 643 1259 570 8720 3950 289 131
130B 8 1714 776 1508 683 1303 590 1714 776 1508 683 1303 590 9050 4100 289 131
NOTE (1): Additional weight for copper coils is per mounting location.
Table 3, Isolator Kit Numbers
AGZ
Model
026, 030
035
040, 045
050
055 060 065, 070
075, 085
090
100 110 120,130
Spring Kit
Part No.
330349603 330349603 330349605 330349606 330349607 330349609 330349612 330349613 330349614
R-I-S Kit
Part No.
330349702 330349703 330349704 330349704 330349705 330349706 330349707 330349708 330349709
Table 4, Isolator Locations
AGZ-B, Chillers
Operating Weight. Neoprene-In-Shear Mountings Spring-Flex Mountings
Unit
Size
lbs kg
1 2 3 4 5 6 1 2 3 4 5 6
026B 3990 1807
Black Gray Gray Gray - - Orange Purple Purple Red - -
030B 4040 1830
Black Gray Gray Gray - - Orange Purple Purple Red - -
035B 4080 1848
Black Gray Gray Gray - - Orange Purple Purple Red - -
040B 4130 1871
Black Gray Black Gray - - Orange Purple Purple Red - -
045B 4270 1934
Black Gray Black Gray - - Orange Purple Purple Red - -
050B 4400 1993
Black Gray Black Gray - - Orange Purple Purple Red - -
055B 4540 2057
Black Black Black Gray - - Orange Purple Purple Purple - -
060B 4600 2084
Black Black Black Gray - - Orange Purple Orange Purple - -
065B 4860 2202
Black Black Black Black - - Orange Orange Orange Purple - -
070B 4990 2260
Black Black Black Black - - Orange Orange Orange Purple - -
075B 6530 2958
Red Black Red Black - - Gray Orange Gray Orange - -
085B 6690 3031
Red Black Red Black - - Gray Orange Gray Orange - -
090B 6850 3103
Red Black Red Black - - Gray Orange Gray Orange - -
100B 7870 3565
Black Black Black Black Black Black Orange Orange Orange Orange Orange Orange
110B 8150 3692
Red Black Black Red Black Black Green Orange Orange Green Orange Orange
120B 8720 3950
Red Red Black Red Red Black Green Green Orange Green Green Orange
130B 9050 4100
Red Red Black Red Red Black Green Green Orange Green Green Orange
NOTES:
1. Neoprene-in-shear isolators: Gray=RP-3 Gray, Black=RP-4 Black, Red=RP-4 Red.
