McQuay AGZ045BS User Manual

76 AGZ 026B through 130B IOMM AGZ-5
Fine Tuning Functions
“B” Group Parameters
Function
Code
Name
McQuay
Setting
B_01 Selection of automatic restart 00
B_02
Allowable under-voltage power failure
time
1.0
B_03 Retry wait time before motor restart 1.0
B_12 Level of electronic thermal setting
Rated
current for
each
inverter
B_13 Electronic thermal characteristic
01
B_21 Overload restriction operation mode
01
B_22 Overload restriction setting
Rated
current x
1.25
B_23 Deceleration rate at overload restriction
1.0
B_31 Software lock mode selection
01
B_32 Reactive current setting
Rated
current x
0.58
B_81 {FM] terminal analog meter adjustment
80
B_82 Start frequency adjustment
0.5
B_83 Carrier frequency setting
5.0
B_84
Initialization mode (parameters or trip
history)
00
B_85 Country code for initialization
02
B_86 Frequency scaling conversion factor
1.0
B_87 STOP key enable
00
B_88 Restart mode after FRS
00
B_89 Data select for digital op. OPE-J
01
Intelligent Terminal Functions
“C” Group Parameters
Function
Code
Name
McQuay
Setting
C_01 Terminal [1] function 00
C_02 Terminal [2] function 01
C_03 Terminal [3] function 16
C_04 Terminal [4] function
13
C_05 Terminal [5] function
18
C_11 Terminal [1] active state
00
C_12 Terminal [2] active state
00
C_13 Terminal [3] active state
00
C_14 Terminal [4] active state
01
C_15 Terminal [5] active state
00
C_21 Terminal [11] function
01
C_22 Terminal [12] function
00
C_23 [FM] signal selection
00
Terminal [11] active state (-FU)
00
C_31
Reserved (-FE / FR)
Terminal [12] active state (-FU)
00
C_32
Terminal [11] active state (-FE / FR)
C_33 Alarm relay terminal active state
01
C_41 Overload level setting
Inverter
rated
current
C_42 Frequency arrival setting for accel
0.0
C_43 Arrival frequency setting for decel
0.0
C_44 PID deviation level setting
3.0
C_91 Debug mode enable
00
