34 AGZ 026B through 130B IOMM AGZ-5
Table 20, AGZ 026BM/BS – 070BM/BS, Compressor and Fan Motor Amps, Single and
Multi-Point (Up to 105°F)
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line
AGZ
Unit
Size
Volts
No. 1 No. 3 No. 5 No. 2 No. 4 No. 6
F.L.Amps
Fan
Motors
(Each)
No. Of
Fan
Motors
Fan
Motors
(Each)
No.1 No. 3 No. 5 No.2 No.4 No. 6
208 25.7 25.7 - 25.7 25.7 - 5.8 4 23.3 189 189 - 189 189 -
230 24.2 24.2 - 24.2 24.2 - 5.8 4 26.1 189 189 - 189 189 -
380 14.9 14.9 - 14.9 14.9 - 4.1 4 20.0 112 112 - 112 112 -
460 13.4 13.4 - 13.4 13.4 - 2.8 4 13.0 99 99 - 99 99 -
026B
575 9.3 9.3 - 9.3 9.3 - 3.0 4 14.0 74 74 - 74 74 -
208 25.7 25.7 - 31.8 31.8 - 5.8 4 23.3 189 189 - 232 232 -
230 24.2 24.2 - 31.8 31.8 - 5.8 4 26.1 189 189 - 232 232 -
380 14.9 14.9 - 18.6 18.6 - 4.1 4 20.0 112 112 - 144 144 -
460 13.4 13.4 - 16.0 16.0 - 2.8 4 13.0 99 99 - 125 125 -
030B
575 9.3 9.3 - 12.2 12.2 - 3.0 4 14.0 74 74 - 100 100 -
208 31.8 31.8 - 31.8 31.8 - 5.8 4 23.3 232 232 - 232 232 -
230 29.9 29.9 - 29.9 29.9 - 5.8 4 26.1 232 232 - 232 232 -
380 18.6 18.6 - 18.6 18.6 - 4.1 4 20.0 144 144 - 144 144 -
460 16.0 16.0 - 16.0 16.0 - 2.8 4 13.0 125 125 - 125 125 -
035B
575 12.2 12.2 - 12.2 12.2 - 3.0 4 14.0 100 100 - 100 100 -
208 33.8 33.8 - 33.8 33.8 - 5.8 4 23.3 278 278 - 278 278 -
230 33.8 33.8 - 33.8 33.8 - 5.8 4 26.1 278 278 - 278 278 -
380 22.8 22.8 - 22.8 22.8 - 4.1 4 20.0 151 151 - 151 151 -
460 16.5 16.5 - 16.5 16.5 - 2.8 4 13.0 127 127 - 127 127 -
040B
575 13.7 13.7 - 13.7 13.7 - 3.0 4 14.0 100 100 - 100 100 -
208 33.8 33.8 - 41.4 41.4 - 5.8 4 23.3 278 278 - 350 350 -
230 33.8 33.8 - 41.4 41.4 - 5.8 4 26.1 278 278 - 350 350 -
380 22.8 22.8 - 26.0 26.0 - 4.1 4 20.0 151 151 - 195 195 -
460 16.5 16.5 - 21.8 21.8 - 2.8 4 13.0 127 127 - 158 158 -
045B
575 13.7 13.7 - 17.3 17.3 - 3.0 4 14.0 100 100 - 125 125 -
208 41.4 41.4 - 41.4 41.4 - 5.8 4 23.3 350 350 - 350 350 -
230 41.4 41.4 - 41.4 41.4 - 5.8 4 26.1 350 350 - 350 350 -
380 26.0 26.0 - 26.0 26.0 - 4.1 4 20.0 195 195 - 195 195 -
460 21.8 21.8 - 21.8 21.8 - 2.8 4 13.0 158 158 - 158 158 -
050B
575 17.3 17.3 - 17.3 17.3 - 3.0 4 14.0 125 125 - 125 125 -
208 41.0 41.0 - 51.3 51.3 - 5.8 4 23.3 350 350 - 425 425 -
230 41.0 41.0 - 48.1 48.1 - 5.8 4 26.1 350 350 - 425 425 -
380 26.0 26.0 - 33.8 33.8 - 4.1 4 20.0 195 195 - 239 239 -
460 21.8 21.8 - 23.7 23.7 - 2.8 4 13.0 158 158 - 187 187 -
055B
575 17.3 17.3 - 21.8 21.8 - 3.0 4 14.0 125 125 - 148 148 -
208 52.8 52.8 - 52.8 52.8 - 5.8 4 23.3 425 425 - 425 425 -
230 48.1 48.1 - 48.1 48.1 - 5.8 4 26.1 425 425 - 425 425 -
380 32.7 32.7 - 32.7 32.7 - 4.1 4 20.0 239 239 - 239 239 -
460 23.7 23.7 - 23.7 23.7 - 2.8 4 13.0 187 187 - 187 187 -
060B
575 21.8 21.8 - 21.8 21.8 - 3.0 4 14.0 148 148 - 148 148 -
208 52.8 52.8 - 52.8 73.1 - 7.8 4 31.7 425 425 - 425 505 -
230 52.8 52.8 - 52.8 73.1 - 7.8 4 35.6 425 425 - 425 505 -
380 32.7 32.7 - 32.7 38.2 - 4.1 4 20.0 239 239 - 239 280 -
460 23.7 23.7 - 23.7 30.1 - 3.6 4 17.8 187 187 - 187 225 -
065B
575 21.8 21.8 - 21.8 25.2 - 3.0 4 14.0 148 148 - 148 180 -
208 52.8 73.1 - 52.8 73.1 - 7.8 4 31.7 425 505 - 425 505 -
230 52.8 73.1 - 52.8 73.1 - 7.8 4 35.6 425 505 - 425 505 -
380 32.7 38.2 - 32.7 38.2 - 4.1 4 20.0 239 280 - 239 280 -
460 23.7 30.1 - 23.7 30.1 - 3.6 4 17.8 187 225 - 187 225 -
070B
575 21.8 25.2 - 21.8 25.2 - 3.0 4 14.0 148 180 - 148 180 -
All Electrical Data notes are on page 49.
