IOMM AGZ-5 AGZ 026B through 130B 39
Table 25, AGZ 026BM/BS – 070BM/BS, Electrical Data, Multi-Point (Up to 105°F)
Electrical Circuit #1 Electrical Circuit #2
Power Supply Power Supply
Field Wire Field Wire
AGZ
Unit
Size
Volts
Minimum
Circuit
Ampacity
(MCA)
Qty
Wire
Gauge
Recomm’d
Fuse
or HACR
Breaker
Size
Max. Fuse
or HACR
Breaker
Size
Minimum
Circuit
Ampacity
(MCA)
Qty
Wire
Gauge
Recomm’d
Fuse
or HACR
Breaker
Size
Max.
Fuse
or HACR
Breaker
Size
208
70
3
#4
80
90
70
3
#4
80
90
230 66 3 #4 80 90 66 3 #4 80 90
380 42 3 #8 50 50 42 3 #8 50 50
460 36 3 #8 45 45 36 3 #8 45 45
026B
575 27 3 #10 35 35 27 3 #10 35 35
208
70
3
#4
80
90
83
3
#4
100
110
230 66 3 #4 80 90 83 3 #4 100 100
380 42 3 #8 50 50 50 3 #8 60 60
460 36 3 #8 45 45 42 3 #8 50 50
030B
575 27 3 #10 35 35 34 3 #10 40 45
208
83
3
#4
100
110
83
3
#4
100
110
230 79 3 #4 100 100 79 3 #4 100 100
380 50 3 #8 60 60 50 3 #8 60 60
460 42 3 #8 50 50 42 3 #8 50 50
035B
575 34 3 #10 40 45 34 3 #10 40 45
208
88
3
#3
110
110
88
3
#3
110
110
230 88 3 #3 110 100 88 3 #3 110 100
380 60 3 #6 70 80 60 3 #6 70 80
460 43 3 #8 50 50 43 3 #8 50 50
040B
575 37 3 #8 45 50 37 3 #8 45 50
208
88
3
#3
110
110
105
3
#2
125
125
230 88 3 #3 110 110 105 3 #2 125 125
380 60 3 #6 70 80 67 3 #4 80 80
460 43 3 #8 50 50 55 3 #6 70 70
045B
575 37 3 #8 45 50 45 3 #8 50 60
208
105
3
#2
125
125
105
3
#2
125
125
230 105 3 #2 125 125 105 3 #2 125 125
380 67 3 #4 80 80 67 3 #4 80 80
460 55 3 #6 70 70 55 3 #6 70 70
050B
575 45 3 #8 50 60 45 3 #8 50 60
208
105
3
#2
125
125
120
3
#1
150
150
230 105 3 #2 125 125 120 3 #1 150 150
380 67 3 #4 80 80 82 3 #3 100 110
460 55 3 #6 70 70 59 3 #6 70 80
055B
575 45 3 #8 50 60 55 3 #6 70 70
208
120
3
#1
150
150
120
3
#1
150
150
230 120 3 #1 150 150 120 3 #1 150 150
380 82 3 #3 100 110 82 3 #3 100 110
460 59 3 #6 70 80 59 3 #6 70 80
060B
575 55 3 #6 70 70 55 3 #6 70 70
208
135
3
1/0
175
175
160
3
2/0
200
225
230 135 3 1/0 175 175 160 3 2/0 200 225
380 82 3 #4 100 110 89 3 #3 110 125
460 61 3 #6 70 80 69 3 #4 90 100
065B
575 55 3 #6 70 70 59 3 #6 70 80
208
160
3
2/0
200
225
160
3
2/0
200
225
230 160 3 2/0 200 225 160 3 2/0 200 225
380 89 3 #3 110 125 89 3 #3 110 125
460 69 3 #4 90 100 69 3 #4 90 100
070B
575 59 3 #6 70 80 59 3 #6 70 80
NOTES:
1. All Electrical Data notes are on page 49.
