IOMM AGZ-5 AGZ 026B through 130B 75
Standard Functions
“A” Group Parameters
Function
Code
Name
McQuay
Setting
A_01 Frequency source setting 01
A_02 Run command source setting 01
A_03 Base frequency setting 60.0
A_04 Maximum frequency setting
60.0
A_11 O-L input active range start frequency
0
A_12 O-L input active range end frequency
0
A_13 O-L input active range start voltage
0
A_14 O-L input active range end voltage
100
A_15 O-L input start frequency enable
01
A_16 External frequency filter time constant
8
A_20 Multi-speed 0 setting
0
A_21 Multi-speed 1 setting
0
A_22 Multi-speed 2 setting
0
A_23 Multi-speed 3 setting
0
A_24 Multi-speed 4 setting
0
A_25
Multi-speed 5 setting
0
A_26 Multi-speed 6 setting
0
A_27 Multi-speed 7 setting
0
A_28 Multi-speed 8 setting
0
A_29 Multi-speed 9 setting
0
A_30 Multi-speed 10 setting
0
A_31 Multi-speed 11 setting
0
A_32 Multi-speed 12 setting
0
A_33 Multi-speed 13 setting
0
A_34 Multi-speed 14 setting
0
A_35 Multi-speed 15 setting
0
A_38 Jog frequency setting
1.0
A_39 Jog stop mode
00
A_41 Torque boost method selection
00
A_42 Manual torque boost value
11
A_43
Manual torque boost frequency
adjustment
10.0
A_44 V/f characteristic curve selection
00
A_45 V/f gain setting
100
A_51 DC braking enable
00
A_52 DC braking frequency setting
0.5
“A” Group Parameters
Function
Code
Name
McQuay
Setting
A_53 DC braking wait time 0.0
A_54 DC braking force during deceleration 0
A_55
DC braking time during deceleration
0.0
A_61 Frequency upper limit setting
0.0
A_62 Frequency lower limit setting
0.0
A_63,
A_65,
A_67
Jump (center) frequency setting
0.0
A_64-
A_66
A_68
Jump (hysteresis) frequency width
setting
0.5
A_71 PID Enable
00
A_72 PID proportional gain
1.0
A_73 PID integral time constant
1.0
A_74 PID derivative gain
0.0
A_75 PV scale conversion
1.00
A_76 PV source setting
00
A_81 AVR function select
00
A_82 AVR voltage select
230/460
A_92 Second acceleration time setting
15.0
A_93 Second deceleration time setting
15.0
A_94
Select method to switch to second
accel/decel profile
00
A_95 Acc1 to Acc2 frequency transition point
0.0
A_96
Dec1 to Dec2 frequency transition
point
0.0
A_97 Acceleration curve selection
00
A_98 Deceleration curve selection
00
