Model Number Description
Table 2: Model Number Description: Fields 21 - 41
22
Not currently used
• YY = none
23 Reheat Coil Type
• W1 = 1-row water
• S1 = 1-row steam
• YY = none
24 Reheat Coil Fins Per Inch
• 12 = 12 fins per inch
25 Reheat Coil Connection Hand
•L = left hand
• R = right hand
• Y = none
26 Reheat Coil Piping Package
• F = factor installed
• L = shipped loose
• Y = none
27 Reheat Coil Connection Type
•S = sweated
• T = threaded
• N = none
28 Electric Heat Power Supply
• A = 115-60-1
• E = 208-230/60/1
• J = 277-265/60/1
•Y = None
29 Electric Heat Wattage
• 005 = 0.5 kW Electric Heat
• 010 = 1.0 kW Electric Heat
• 015 = 1.5 kW Electric Heat
• 020 = 2.0 kW Electric Heat
• 025 = 2.5 kW Electric Heat
• 030 = 3.0 kW Electric Heat
• 040 = 4.0 kW Electric Heat
• 050 = 5.0 kW Electric Heat
• 060 = 6.0 kW Electric Heat
• 000 = None
30 Not currently used
• YY = none
31 Drain Pan Material
• P = plastic, non-corrosive
• S = stainless steel
32 Blower Motor Type
• PSC = PSC motor
• XXX = special
33 Discharge Conditions
• S = standard static
34 Motor Speed
• 3 = 3 speed
35 Motor Connections
• Q = quick connect
36 Not currently used
• YY = none
37 Fresh Air Damper
• MR = manual rear
• 2R = automatic, 2-position, rear
• ER = automatic, economizer
• XX = special
• YY = none
38 Not currently used
• YYY = none
39 Unit Disconnect Switch
• D = toggle disconnect switch
• X = special
• Y = none
40 Future Control Function
• Y = none
41 Control Type
• A = analog
• D = digital
•R = DDC Ready
• X = Special
• Y = None
Field
22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41
Code
YY W1 12 R F T Y 000 Y P PSC S 3 Q Y MR Y D Y R
