1
1. Transmission source
• The source where the signal will be transmitted.
2. Signal transmission indication
• Blink to confirm that the last setting has been transmitted to the unit.
3. “ON/OFF” Button
• Press once to start the air conditioner unit.
• Press again to stop the unit.
4. Temperature setting
• To set the desired room temperature, press the + or -- button to increase or de-
crease the set temperature.
• The temperature setting range is from 16°C to 30°C (Optional setting 20°C to
30°C).
• Press both buttons simultaneously to toggle + and -- from °C to °F setting.
5. Operation mode
• Press the MODE button to select the type of operating mode.
•
For cooling only unit, the available modes are: COOL ( ), DRY ( ) and FAN ( ).
• For heat pump unit, the available modes are: COOL ( ), DRY ( ), FAN ( ) and
HEAT ( ).
6. Fan speed selection
• Press the button continuously will toggle the fan speed in the following order:
Low –––
:
Med –––
:
High –––
:
Auto
• Stop pressing when the desired fan speed appears on the display screen.
7. ON timer setting
• Press the SET button will activate the on timer function.
• Set the desired on time by pressing the SET button continuously. If the timer is
set to 7.30am, the air conditioner will turn on at 7.30am sharp.
• Press the CLR button to cancel the on timer setting.
8. OFF timer setting
• Press the SET button will activate the off timer function.
• Set the desired off time by pressing the SET button continuously.
• Press the CLR button to cancel the off timer setting.
9. Automatic air swing (optional)
• Press the SWING button to activate the automatic air swing function.
• To distribute the air to a specific direction, press the SWING button and wait
until the louver move to the desired direction and press the button once again.
OPERATING GUIDE
ENGLISH
OM-G11(CW)-0704-Acson 11/28/05, 2:49 PM1
