McQuay M4MC100D User Manual

58
HEATING (R22)
MODEL : MDB150DR vs. MMC150DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
11,659 12,381 13,025 13,669 14,313 15,086 15,602 15,859 16,117
15
11,761 12,938 13,988 15,038 16,089 17,349 18,189 18,609 19,030
16.7
11,987 13,206 14,294 15,382 16,470 17,775 18,646 19,081 19,516
18
12,160 13,411 14,527 15,644 16,761 18,101 18,994 19,441 19,888
19.4
12,346 12,749 13,110 13,470 15,562 18,072 19,745 20,582 21,419
20
12,426 13,703 14,843 15,983 17,123 18,491 19,403 19,859 20,315
22
12,692 13,940 15,054 16,169 17,283 18,621 19,512 19,958 20,404
22.2
12,718 13,963 15,075 16,187 17,299 18,633 19,523 19,968 20,413
24
11,450 12,527 13,489 14,451 15,414 16,568 17,338 17,723 18,108
MODEL : MDB150DR2 vs. MMC075DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
13,016 14,197 15,252 16,307 17,362 18,628 19,472 19,894 20,316
15
11,457 12,774 13,950 15,127 16,303 17,715 18,656 19,126 19,597
16.7
11,828 13,076 14,190 15,303 16,417 17,754 18,645 19,090 19,536
18
12,113 13,307 14,373 15,439 16,505 17,784 18,637 19,063 19,489
19.4
12,419 13,931 15,282 16,632 16,988 17,416 17,701 17,844 17,986
20
12,550 13,703 14,732 15,762 16,791 18,026 18,850 19,261 19,673
22
12,987 14,196 15,274 16,353 17,432 18,726 19,589 20,021 20,452
22.2
13,031 14,245 15,329 16,412 17,496 18,796 19,663 20,097 20,530
24
14,137 15,468 16,656 17,844 19,032 20,457 21,408 21,883 22,358
MODEL : MDB200DR2 vs. MMC100DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
17,640 19,010 20,233 21,456 22,679 24,147 25,126 25,615 26,104
15
15,907 17,318 18,578 19,838 21,098 22,610 23,618 24,122 24,626
16.7
16,104 17,564 18,868 20,171 21,475 23,039 24,082 24,603 25,125
18
16,255 17,752 19,089 20,426 21,763 23,367 24,436 24,971 25,506
19.4
16,417 18,263 19,911 21,560 22,696 24,060 24,969 25,424 25,878
20
16,486 18,031 19,411 20,790 22,170 23,825 24,929 25,481 26,032
22
16,718 18,288 19,690 21,091 22,493 24,176 25,297 25,858 26,419
22.2
16,741 18,313 19,717 21,122 22,526 24,211 25,334 25,896 26,457
24
18,326 20,051 21,591 23,131 24,671 26,519 27,751 28,367 28,983
MODEL : MDB250DR2 vs. MMC125DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
19,152 20,498 21,700 22,901 24,103 25,545 26,506 26,987 27,468
15
19,070 20,856 22,451 24,045 25,640 27,553 28,829 29,466 30,104
16.7
19,367 21,205 22,847 24,488 26,129 28,098 29,411 30,068 30,724
18
19,595 21,473 23,149 24,826 26,503 28,515 29,856 30,527 31,198
19.4
19,839 20,905 21,856 22,808 25,220 28,114 30,043 31,008 31,973
20
19,944 21,868 23,586 25,303 27,021 29,082 30,457 31,144 31,831
22
20,294 22,227 23,953 25,679 27,406 29,477 30,858 31,549 32,239
22.2
20,329 22,263 23,990 25,717 27,444 29,517 30,898 31,589 32,280
All power units in watts
