McQuay M4MC100D User Manual

59
HEATING (R22)
MODEL : MDB300DR2 vs. MMC150DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
25,068 26,468 27,718 28,968 30,218 31,718 32,718 33,218 33,719
15
25,525 27,833 29,893 31,953 34,013 36,486 38,134 38,958 39,782
16.7
25,843 28,291 30,476 32,662 34,847 37,469 39,218 40,092 40,966
18
26,086 28,641 30,922 33,203 35,484 38,222 40,047 40,959 41,872
19.4
26,347 27,056 27,688 28,320 33,269 39,208 43,167 45,147 47,127
20
26,460 29,116 31,487 33,859 36,230 39,076 40,973 41,922 42,871
22
26,833 29,442 31,770 34,099 36,428 39,223 41,086 42,018 42,949
22.2
26,871 29,474 31,799 34,123 36,448 39,238 41,097 42,027 42,957
24
24,072 26,338 28,360 30,383 32,406 34,834 36,452 37,261 38,070
MODEL : MDB400DR4 vs. MMC100DR x 4
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
35,580 38,327 40,781 43,234 45,687 48,630 50,593 51,574 52,555
15
32,110 34,939 37,465 39,992 42,518 45,549 47,570 48,581 49,591
16.7
32,496 35,422 38,035 40,648 43,260 46,396 48,486 49,531 50,576
18
32,791 35,791 38,470 41,149 43,828 47,043 49,186 50,258 51,329
19.4
33,109 36,810 40,115 43,420 45,693 48,420 50,238 51,147 52,056
20
33,245 36,343 39,109 41,874 44,640 47,959 50,172 51,278 52,385
22
33,699 36,855 39,673 42,491 45,309 48,690 50,945 52,072 53,199
22.2
33,744 36,906 39,729 42,553 45,376 48,763 51,022 52,151 53,280
24
36,907 40,381 43,482 46,583 49,685 53,407 55,888 57,128 58,369
MODEL : MDB500DR4 vs. MMC125DR x 4
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
40,804 43,559 46,019 48,478 50,938 53,890 55,858 56,842 57,826
15
40,600 44,230 47,472 50,714 53,956 57,846 60,440 61,736 63,033
16.7
41,131 44,860 48,189 51,519 54,848 58,844 61,507 62,839 64,171
18
41,537 45,341 48,738 52,134 55,531 59,606 62,324 63,682 65,041
19.4
41,974 44,179 46,147 48,116 52,940 58,728 62,587 64,516 66,446
20
42,162 46,073 49,565 53,057 56,549 60,740 63,534 64,930 66,327
22
42,786 46,785 50,355 53,925 57,495 61,779 64,635 66,063 67,491
22.2
42,849 46,856 50,434 54,012 57,590 61,883 64,745 66,177 67,608
24
40,899 44,748 48,185 51,622 55,058 59,183 61,932 63,307 64,682
All power units in watts
