McQuay M4MC100D User Manual

63
HEATING (R407C)
MODEL : MDB075DR vs. M4MC075DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
7,157 7,608 8,012 8,415 8,818 9,302 9,624 9,785 9,947
15
6,298 6,904 7,445 7,987 8,528 9,178 9,611 9,827 10,044
16.7
6,405 7,031 7,589 8,147 8,706 9,376 9,822 10,046 10,269
18
6,488 7,128 7,699 8,270 8,841 9,527 9,984 10,213 10,441
19.4
6,577 7,197 7,751 8,305 8,844 9,491 9,922 10,138 10,354
20
6,615 7,269 7,853 8,437 9,021 9,722 10,190 10,423 10,657
22
6,741 7,392 7,972 8,553 9,134 9,830 10,295 10,527 10,759
22.2
6,754 7,404 7,984 8,565 9,145 9,841 10,305 10,538 10,770
24
7,059 7,724 8,317 8,910 9,503 10,215 10,690 10,927 11,164
MODEL : MDB100DR vs. M4MC100DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
8,230 9,013 9,713 10,412 11,111 11,950 12,510 12,790 13,069
15
8,256 8,980 9,626 10,272 10,918 11,693 12,210 12,469 12,727
16.7
8,328 9,139 9,863 10,586 11,310 12,179 12,758 13,047 13,337
18
8,383 9,260 10,044 10,827 11,610 12,550 13,177 13,490 13,803
19.4
8,442 9,242 9,956 10,670 11,242 11,929 12,387 12,616 12,845
20
8,467 9,399 10,230 11,062 11,893 12,891 13,556 13,889 14,221
22
8,552 9,424 10,202 10,981 11,760 12,694 13,317 13,628 13,940
22.2
8,560 9,426 10,200 10,973 11,746 12,674 13,293 13,602 13,911
24
9,070 9,923 10,685 11,447 12,210 13,124 13,734 14,039 14,344
MODEL : MDB125DR vs. M4MC125DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
9,810 10,362 10,855 11,348 11,841 12,432 12,826 13,023 13,221
15
9,434 10,332 11,134 11,936 12,737 13,700 14,341 14,662 14,982
16.7
9,595 10,507 11,321 12,136 12,950 13,928 14,579 14,905 15,231
18
9,718 10,641 11,465 12,289 13,113 14,102 14,761 15,091 15,421
19.4
9,850 10,299 10,699 11,100 12,495 14,170 15,286 15,845 16,403
20
9,907 10,846 11,684 12,523 13,361 14,367 15,038 15,373 15,709
22
10,096 11,049 11,901 12,752 13,604 14,625 15,306 15,647 15,987
22.2
10,115 11,070 11,922 12,775 13,628 14,651 15,333 15,674 16,015
24
9,435 10,323 11,116 11,909 12,702 13,653 14,287 14,604 14,922
MODEL : MDB150DR2 vs. M4MC150DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
12,565 13,247 13,855 14,464 15,073 15,803 16,290 16,534 16,777
15
12,647 13,884 14,989 16,093 17,198 18,523 19,407 19,848 20,290
16.7
12,866 14,166 15,327 16,487 17,648 19,041 19,970 20,434 20,898
18
13,033 14,381 15,585 16,789 17,993 19,437 20,400 20,882 21,364
19.4
13,212 13,535 13,822 14,110 15,845 17,927 19,315 20,009 20,703
20
13,289 14,677 15,915 17,154 18,392 19,878 20,869 21,365 21,860
22
13,546 14,889 16,089 17,288 18,487 19,926 20,886 21,365 21,845
22.2
13,572 14,911 16,106 17,301 18,497 19,931 20,887 21,365 21,843
24
11,994 13,122 14,130 15,138 16,146 17,355 18,162 18,565 18,968
All power units in watts
