HEATING (R407C)
MODEL : MDB150DR2 vs. M4MC075DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
14,594 15,500 16,309 17,119 17,928 18,899 19,546 19,870 20,194
15
12,869 14,086 15,172 16,258 17,344 18,648 19,517 19,951 20,386
16.7
13,075 14,331 15,452 16,573 17,694 19,039 19,936 20,384 20,832
18
13,233 14,518 15,666 16,813 17,961 19,338 20,256 20,715 21,174
19.4
13,403 14,649 15,761 16,874 17,959 19,262 20,130 20,565 20,999
20
13,475 14,792 15,968 17,144 18,320 19,731 20,671 21,142 21,612
22
13,718 15,033 16,208 17,382 18,557 19,966 20,906 21,375 21,845
22.2
13,742 15,057 16,232 17,406 18,580 19,990 20,929 21,399 21,869
24
14,343 15,693 16,898 18,103 19,309 20,755 21,719 22,201 22,683
MODEL : MDB200DR2 vs. M4MC100DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
17,240 18,826 20,242 21,659 23,075 24,774 25,907 26,474 27,040
15
17,280 18,746 20,054 21,363 22,671 24,242 25,288 25,812 26,335
16.7
17,404 19,042 20,504 21,966 23,429 25,184 26,354 26,939 27,524
18
17,498 19,268 20,848 22,428 24,008 25,904 27,168 27,800 28,432
19.4
17,600 19,223 20,671 22,120 23,265 24,638 25,554 26,011 26,469
20
17,644 19,526 21,207 22,888 24,568 26,585 27,930 28,602 29,274
22
17,789 19,575 21,169 22,762 24,356 26,269 27,544 28,182 28,819
22.2
17,804 19,579 21,165 22,750 24,335 26,237 27,506 28,140 28,774
24
18,802 20,572 22,152 23,732 25,312 27,208 28,472 29,104 29,736
MODEL : MDB250DR2 vs. M4MC125DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
21,080 22,221 23,240 24,258 25,277 26,499 27,314 27,722 28,129
15
20,304 22,135 23,769 25,404 27,038 28,999 30,307 30,961 31,614
16.7
20,589 22,444 24,101 25,757 27,414 29,401 30,727 31,389 32,052
18
20,806 22,681 24,354 26,027 27,701 29,709 31,048 31,717 32,386
19.4
21,041 21,981 22,821 23,660 26,451 29,800 32,033 33,149 34,265
20
21,141 23,056 24,766 26,476 28,186 30,238 31,606 32,290 32,974
22
21,476 23,460 25,232 27,003 28,774 30,900 32,317 33,026 33,734
22.2
21,510 23,501 25,278 27,056 28,833 30,966 32,388 33,099 33,810
24
20,111 22,004 23,694 25,384 27,074 29,102 30,454 31,130 31,806
MODEL : MDB300DR2 vs. M4MC150DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
27,020 28,344 29,526 30,708 31,890 33,309 34,254 34,727 35,200
15
27,212 29,659 31,843 34,028 36,213 38,834 40,582 41,456 42,330
16.7
27,531 30,156 32,501 34,845 37,190 40,003 41,879 42,817 43,754
18
27,774 30,537 33,004 35,470 37,937 40,897 42,871 43,857 44,844
19.4
28,036 28,648 29,194 29,740 33,524 38,064 41,091 42,604 44,118
20
28,149 31,034 33,610 36,187 38,763 41,854 43,915 44,946 45,976
22
28,524 31,326 33,829 36,331 38,833 41,836 43,838 44,839 45,840
22.2
28,561 31,355 33,850 36,345 38,840 41,834 43,830 44,828 45,826
24
25,279 27,658 29,782 31,907 34,031 36,580 38,280 39,129 39,979
All power units in watts
