Outdoor Unit
Model: M5LC 007C
No Descriptions Part No No Descriptions Part No
1
A
ssy., Base Pan
A
50014057372 10 Left Panel
A
01014052510
2
A
ssy., Condenser Coil
A
50024064720 11 Right Panel
A
01014052509
3 Valve Bracket
A
01014051164 12
A
ssy. Control Panel
A
50044054806
4 Compressor
A
04019019592 13
A
ssy., Front Panel
A
01014052512
5 Assy., Partition A50064065275 14 Assy., Valve Cover A50124055172
6
A
ssy., Cap Tube
A
50024064527 15
A
ssy., Front Grille
A
50124056905
7 Bracket, Fan Motor A01014052516 16 Plastic, Handle A12014057948
8 Fan Motor
A
03039015324 17 Rubber Grommet
A
11059011558
9 Fan Blade
A
03019004131 18
A
ssy., Flare Valve 2 Ways 1/4"
A
50059019453
19
A
ssy., Flare Valve 3 Ways 3/8"
A
50059019454
