McQuay M5WM 015GR User Manual

21
HEATING MODE
R22 Models
(Heatpump)
Model : MWM 009GR / MLC 009CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.164 2.057 2.935 1.847 2.706 1.636 2.477 1.426 2.248 1.215 1.973 0.963
16
3.206 1.890 2.979 1.699 2.753 1.508 2.526 1.317 2.299 1.126 2.028 0.897
16
3.206 2.414 2.979 2.223 2.753 2.032 2.526 1.841 2.299 1.650 2.028 1.421
17 3.247 2.247 3.023 2.076 2.799 1.904 2.575 1.733 2.351 1.562 2.083 1.356
18 3.288 2.080 3.067 1.928 2.846 1.777 2.624 1.625 2.403 1.473 2.138 1.291
19 3.330 1.913 3.111 1.781 2.892 1.649 2.674 1.516 2.455 1.384 2.192 1.225
20 3.371 1.746 3.159 1.633 2.947 1.520 2.735 1.407 2.523 1.293 2.269 1.158
18
3.288 2.604 3.067 2.452 2.846 2.301 2.624 2.149 2.403 1.997 2.138 1.815
19
3.330 2.437 3.111 2.305 2.892 2.173 2.674 2.040 2.455 1.908 2.192 1.749
20 3.371 2.270 3.159 2.157 2.947 2.044 2.735 1.931 2.523 1.817 2.269 1.682
21 3.414 2.103 3.211 2.009 3.008 1.914 2.805 1.820 2.603 1.726 2.359 1.613
22 3.456 1.936 3.262 1.860 3.069 1.785 2.876 1.709 2.682 1.634 2.450 1.543
23 3.498 1.769 3.314 1.712 3.130 1.656 2.946 1.599 2.762 1.542 2.541 1.474
24
3.540 1.602 3.365 1.564 3.191 1.526 3.016 1.488 2.841 1.451 2.631 1.405
20
3.371 2.532 3.159 2.419 2.947 2.306 2.735 2.193 2.523 2.079 2.269 1.944
21 3.414 2.365 3.211 2.271 3.008 2.176 2.805 2.082 2.603 1.988 2.359 1.875
22 3.456 2.198 3.262 2.122 3.069 2.047 2.876 1.971 2.682 1.896 2.450 1.805
23 3.498 2.031 3.314 1.974 3.130 1.918 2.946 1.861 2.762 1.804 2.541 1.736
24 3.540 1.864 3.365 1.826 3.191 1.788 3.016 1.750 2.841 1.713 2.631 1.667
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
1.201 1.201 1.438 1.438 1.517 1.517 2.386 2.386 2.860 2.860 3.097 3.097 3.334 3.334
17
1.167 1.167 1.419 1.419 1.503 1.503 2.428 2.428 2.834 2.834 3.069 3.069 3.304 3.304
19 1.132 1.132 1.400 1.400 1.490 1.490 2.470 2.470 2.809 2.809 3.041 3.041 3.274 3.274
21
1.098 1.098 1.382 1.382 1.476 1.476 2.512 2.512 2.783 2.783 3.014 3.014 3.245 3.245
23
1.112 1.112 1.375 1.375 1.463 1.463 2.424 2.424 2.758 2.758 2.986 2.986 3.215 3.215
25 1.126 1.126 1.368 1.368 1.449 1.449 2.336 2.336 2.732 2.732 2.959 2.959 3.185 3.185
27
1.14 1.140 1.362 1.362 1.435 1.435 2.248 2.248 2.707 2.707 2.931 2.931 3.155 3.155
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
FROST REGION
