Performance Data MWM-J-2009
Cooling Only (R22)
Model: MWM009J - MLC009C
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.078 1.834 2.841 1.616 2.604 1.398 2.368 1.181 2.131 0.963 1.846 0.702
16 3.080 1.661 2.853 1.472 2.627 1.283 2.401 1.094 2.174 0.905 1.903 0.678
24
16 3.080 2.294 2.853 2.105 2.627 1.916 2.401 1.727 2.174 1.538 1.903 1.311
17 3.081 2.121 2.865 1.961 2.649 1.800 2.434 1.640 2.218 1.479 1.959 1.287
18 3.082 1.949 2.877 1.817 2.672 1.685 2.467 1.553 2.261 1.421 2.015 1.263
19 3.084 1.776 2.889 1.673 2.694 1.569 2.500 1.466 2.305 1.363 2.072 1.239
20 3.085 1.602 2.904 1.521 2.722 1.439 2.541 1.357 2.359 1.275 2.141 1.177
28
18 3.082 2.582 2.877 2.450 2.672 2.318 2.467 2.186 2.261 2.054 2.015 1.896
19 3.084 2.409 2.889 2.306 2.694 2.202 2.500 2.099 2.305 1.996 2.072 1.871
20 3.085 2.235 2.904 2.154 2.722 2.072 2.541 1.990 2.359 1.908 2.141 1.810
21 3.087 2.061 2.920 1.996 2.753 1.931 2.587 1.866 2.420 1.801 2.220 1.723
22 3.089 1.887 2.937 1.839 2.785 1.791 2.633 1.742 2.481 1.694 2.298 1.636
23 3.091 1.713 2.953 1.681 2.816 1.650 2.679 1.618 2.541 1.587 2.377 1.549
24 3.092 1.539 2.970 1.524 2.847 1.509 2.725 1.495 2.602 1.480 2.455 1.462
30
20 3.085 2.552 2.904 2.470 2.722 2.388 2.541 2.306 2.359 2.224 2.141 2.126
21 3.087 2.378 2.920 2.313 2.753 2.248 2.587 2.182 2.420 2.117 2.220 2.039
22 3.089 2.204 2.937 2.155 2.785 2.107 2.633 2.059 2.481 2.010 2.298 1.952
23 3.091 2.030 2.953 1.998 2.816 1.966 2.679 1.935 2.541 1.903 2.377 1.865
24 3.092 1.855 2.970 1.841 2.847 1.826 2.725 1.811 2.602 1.796 2.455 1.778
Model: MWM015J - MLC015C
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.903 2.394 3.660 2.187 3.417 1.980 3.173 1.773 2.930 1.566 2.638 1.317
16 4.018 2.181 3.768 2.001 3.518 1.820 3.268 1.640 3.018 1.459 2.719 1.243
24
16 4.018 2.868 3.768 2.688 3.518 2.507 3.268 2.327 3.018 2.146 2.719 1.930
17 4.132 2.656 3.876 2.502 3.620 2.348 3.363 2.194 3.107 2.040 2.799 1.855
18 4.247 2.444 3.984 2.316 3.721 2.189 3.458 2.061 3.195 1.933 2.880 1.780
19 4.361 2.231 4.092 2.130 3.822 2.029 3.553 1.928 3.284 1.827 2.960 1.706
20 4.476 2.019 4.204 1.939 3.932 1.859 3.659 1.779 3.387 1.699 3.060 1.603
28
18 4.247 3.130 3.984 3.003 3.721 2.875 3.458 2.748 3.195 2.620 2.880 2.467
19 4.361 2.918 4.092 2.817 3.822 2.716 3.553 2.615 3.284 2.514 2.960 2.392
20 4.476 2.705 4.204 2.625 3.932 2.545 3.659 2.466 3.387 2.386 3.060 2.290
21 4.592 2.492 4.319 2.430 4.046 2.367 3.773 2.305 3.500 2.243 3.172 2.168
22 4.707 2.279 4.433 2.234 4.160 2.190 3.886 2.145 3.612 2.100 3.284 2.047
23 4.822 2.065 4.548 2.038 4.274 2.012 4.000 1.985 3.725 1.958 3.396 1.925
24 4.937 1.852 4.663 1.843 4.388 1.834 4.113 1.824 3.838 1.815 3.508 1.804
30
20 4.476 3.049 4.204 2.969 3.932 2.889 3.659 2.809 3.387 2.729 3.060 2.633
21 4.592 2.835 4.319 2.773 4.046 2.711 3.773 2.649 3.500 2.586 3.172 2.512
22 4.707 2.622 4.433 2.577 4.160 2.533 3.886 2.488 3.612 2.444 3.284 2.390
23 4.822 2.409 4.548 2.382 4.274 2.355 4.000 2.328 3.725 2.301 3.396 2.269
24 4.937 2.195 4.663 2.186 4.388 2.177 4.113 2.168 3.838 2.158 3.508 2.147
