Performance Data AWM-J_(ii)
40
Model: AWM25JR – ALC25CR
Heating Mode
ID DB
°C
OUTDOOR WB °C
-9 -6 -5 6 12 15 18
TC SC TC SC TC SC TC SC TC SC TC SC TC SC
15
3.455 3.455 3.910 3.910 4.062 4.062 5.732 5.732 6.643 6.643 7.099 7.099 7.554 7.554
17
3.364 3.364 3.765 3.765 3.966 3.966 5.725 5.725 6.521 6.521 6.972 6.972 7.423 7.423
19
3.274 3.274 3.619 3.619 3.869 3.869 5.719 5.719 6.400 6.400 6.846 6.846 7.293 7.293
21
3.183 3.183 3.517 3.517 3.773 3.773 5.621 5.621 6.278 6.278 6.720 6.720 7.162 7.162
23
3.093 3.093 3.458 3.458 3.676 3.676 5.432 5.432 6.156 6.156 6.594 6.594 7.031 7.031
25
3.002 3.002 3.399 3.399 3.580 3.580 5.244 5.244 6.034 6.034 6.468 6.468 6.901 6.901
27
2.912 2.912 3.340 3.340 3.483 3.483 5.055 5.055 5.913 5.913 6.341 6.341 6.770 6.770
FROST REGION
Part Number: 00061210C2020
Remark:
AFR: Air flow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SHC: Sensible Heat Capacity (kW)
PI: Power Input
Notes:
1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 0 °C to 46°C without pressure trip.
