MWM-J_(ii) Performance Data

Model: M5WM20JR - M5LC20CRJ

Heating Mode

ID DB°C

Outdoor WB°C

-9 -6 -5 6 12 15 18

Q (kW) SC (kW) Q (kW) SC (kW) Q (kW) SC (kW) Q (kW) SC (kW) Q (kW) SC (kW) Q (kW) SC (kW) Q (kW) SC (kW)

15 3.189 3.189 3.610 3.610 3.750 3.750 5.291 5.291 6.132 6.132 6.553 6.553 6.973 6.973

17 3.106 3.106 3.291 3.291 3.664 3.664 5.285 5.285 6.038 6.038 6.457 6.457 6.876 6.876

19 3.022 3.022 2.973 2.973 3.578 3.578 5.279 5.279 5.944 5.944 6.361 6.361 6.778 6.778

21 2.938 2.938 2.854 2.854 3.493 3.493 5.200 5.200 5.849 5.849 6.265 6.265 6.681 6.681

23 2.855 2.855 2.936 2.936 3.407 3.407 5.048 5.048 5.755 5.755 6.169 6.169 6.584 6.584

25 2.771 2.771 3.017 3.017 3.322 3.322 4.896 4.896 5.661 5.661 6.074 6.074 6.487 6.487

27 2.688 2.688 3.099 3.099 3.236 3.236 4.744 4.744 5.567 5.567 5.978 5.978 6.389 6.389

Remark:

AFR: Air ﬂ ow rate (CFM)

EWB: Entering Wet Bulb Temp. (°C)

EDB: Entering Dry Bulb Temp. (°C)

TC: Total Cooling Capacity (kW)

SHC: Sensible Heat Capacity (kW)

PI: Power Input

Notes:

1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.

2. shows nominal capacities.

3. Direct interpolation is permissible. Do not extrapolate.

4. Unit is able to operate at ambient from 0 °C to 46°C without pressure trip.

Part Number : 0652102C2020

McQuay M5WM25JR User Manual
