McQuay MCM 020 D User Manual

Cooling Only (R407C)
MODEL INDOOR UNIT
OUTDOOR UNIT M4LC60C M4LC061C
NOMINAL kcal/h 13860 13610
COOLING W 16120 15830
CAPACITY Btu/h 55000 54000
NOMINAL TOTAL POWER W 6027 5645
NOMINAL TOTAL CURRENT A 10.2 9.5
POWER SOURCE V/Ph/Hz
REFRIGERANT / CONTROL
AIR FLOW cfm / L/s
HIGH
MED
LOW
FAN MOTOR
RATED INPUT POWER W
RATED RUNNING CURRENT A
MATERIAL
DIAMETER mm/in
THICKNESS mm/in
MATERIAL
THICKNESS mm/in
ROW
FIN PER INCH
FACE AREA
m
2
/
ft
2
HEIGHT mm/in
DIMENSION WIDTH mm/in
DEPTH mm/in
WEIGHT kg
CONTROL ROOM TEMPERATURE
OPERATION
CONDENSATE DRAIN SIZE mm/in
AIR FILTER
PACKING HEIGHT mm/in
DIMENSION WIDTH mm/in
DEPTH mm/in
POWER SOURCE V/Ph/Hz
COMPRESSOR TYPE
CAPACITOR µF
--
LOCK ROTOR AMP. A 74 74
RATED RUNNING CURRENT A 8.8 8.6
RATED INPUT POWER W 5045 5060
PROTECTION DEVICE
POWER SOURCE V/Ph/Hz
FAN TYPE / DRIVE
BLADE MATERIAL
DIAMETER mm/in
RATED RUNNING CURRENT A 2.8 1.2
MOTOR OUTPUT W 400 400
RATED INPUT POWER W 655 258
MATERIAL
DIAMETER mm/in
THICKNESS mm/in
MATERIAL
THICKNESS mm/in
ROW 23
FIN PER INCH 16 14
FACE AREA
m
2
/
ft
2
0.87 / 9.33 0.84 / 9.04
HEIGHT mm/in 850 / 33.5 850 / 33.5
DIMENSION WIDTH mm/in
1030 / 40.6 1030 / 40.6
DEPTH mm/in 400 / 15.7 460 / 18.1
WEIGHT kg 105 108
MATERIAL
CASING THICKNESS mm/in
FINISHING
SOUND PRESSURE LEVEL dBA 71 61
TYPE
SIZE LIQUID mm/in
GAS mm/in
PACKING HEIGHT mm/in 1000 /39.4 1016 / 40.0
DIMENSION WIDTH mm/in
1200 / 47.2 1178 / 46.4
DEPTH mm/in 560 / 22.0 602 / 23.7
MCM061C
INDOOR UNIT
220 - 240 / 1 / 50
R407C / CAPILLARY TUBE IN INDOOR
FAN
1550 / 732
SOUND LEVEL (dBA)
56
53
46
2 x 4 POLES x 80 W
327
1.40
COIL
TUBE
S.I.G.C
9.52 / 3/8
0.35 / 0.014
FIN
ALUMINIUM
0.11 / 0.0043
4
14
0.42 / 4.51
285 / 11.2
1874 / 73.8
666 / 26.2
85
MICROCOMPUTER CONTROLLED THERMOSTAT
LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
19.05 / 3/4
WASHABLE SARAN NET
368 / 14.5
1992 / 78.4
760 / 29.9
OUTDOOR UNIT
COMPRESSOR
415 / 3 / 50
SCROLL
OVERLOAD PROTECTION / HI-LO PRESSURE SWITCH
FAN
220 - 240 / 1 / 50
PROPELLER / DIRECT
GLASS REINFORCED ACRLY STYLENE RESIN
600 / 24
COIL
TUBE
S.I.G.C
9.52 / 3/8
0.35 / 0.014
FIN
ALUMINIUM (CORR.)
0.127 / 0.005
ELECTRO GALVANIZED MILD STEEL
1.0 - 2.3 (0.0393 -0.0905)
EPOXY POLYESTER POWDER COATING
PIPE
FLARE VALVE
12.7 / 1/2
19.05 / 3/4
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
26.7°C DB / 19.4°C WB INDOOR AND 46.1°C DB OUTDOOR
Abbreviation
S.B.C. - SEAMLESS BARE COPPER
S.I.G.C - SEAMLESS INNER GROOVE COPPER
Page 11
