McQuay MCM 020 D User Manual

Heat Pump (R407C)
MODEL INDOOR UNIT
MCM061CR
OUTDOOR UNIT
M4LC061CR
NOMINAL kcal/h
14110
HEATING W
16410
CAPACITY Btu/h
56000
NOMINAL kcal/h
13610
COOLING W
15830
CAPACITY Btu/h
54000
NOMINAL TOTAL POWER (COOLING) W
5645
NOMINAL TOTAL POWER (HEATING) W
5145
NOMINAL TOTAL CURRENT (COOLING) A
9.5
NOMINAL TOTAL CURRENT (HEATING) A
9.0
POWER SOURCE V/Ph/Hz
220 - 240 / 1 / 50
REFRIGERANT / CONTROL
R22 / CAPILLARY TUBE - INDOOR (COOLING), OUTDOOR (HEATING)
AIR FLOW cfm / L/s
1550 / 732
HIGH
56
MED
53
LOW
46
FAN MOTOR
2 x 4 POLES x 80 W
RATED INPUT POWER W
327
RATED RUNNING CURRENT A
1.40
MATERIAL
S.I.G.C
DIAMETER mm/in
9.52 / 3/8
THICKNESS mm/in
0.35 / 0.014
MATERIAL
ALUMINIUM
THICKNESS mm/in
0.11 / 0.0043
ROW
4
FIN PER INCH
14
FACE AREA
m
2
/ft
2
0.42 / 4.51
HEIGHT mm/in
285 / 11.2
DIMENSION WIDTH mm/in
1874 / 73.8
DEPTH mm/in
666 / 26.2
WEIGHT kg
85
CONTROL ROOM TEMPERATURE
MICROCOMPUTER CONTROLLED THERMOSTAT
OPERATION
LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
CONDENSATE DRAIN SIZE mm/in
19.05 / 3/4
AIR FILTER
WASHABLE SARAN NET
PACKING HEIGHT mm/in
368 / 14.5
DIMENSION WIDTH mm/in
1992 / 78.4
DEPTH mm/in
760 / 29.9
POWER SOURCE V/Ph/Hz
415 / 3 / 50
COMPRESSOR TYPE
SCROLL
CAPACITOR µF
-
LOCK ROTOR AMP. A
74.0
RATED RUNNING CURRENT (COOLIN
G
A
8.6
RATED RUNNING CURRENT (HEATING
)
A
8.1
RATED INPUT POWER (COOLING) W
5060
RATED INPUT POWER (HEATING) W
4560
PROTECTION DEVICE
OVERLOAD PROTECTION / HI PRESSURE SWITCH
POWER SOURCE V/Ph/Hz
220 - 240 / 1 / 50
FAN TYPE / DRIVE
PROPELLER / DIRECT
BLADE MATERIAL
GLASS REINFORCED ACRLY STYLENE RESIN
DIAMETER mm/in
600 / 24
RATED RUNNING CURRENT A
1.2
MOTOR OUTPUT W
400
RATED INPUT POWER W
258
MATERIAL
S.I.G.C
DIAMETER mm/in
9.52 / 3/8
THICKNESS mm/in
0.35 / 0.014
MATERIAL
ALUMINIUM (CORRUGATED)
THICKNESS mm/in
0.127 / 0.005
ROW
3
FIN PER INCH
14
FACE AREA
m
2
/ft
2
0.84 / 9.04
HEIGHT mm/in
850 / 33.5
DIMENSION WIDTH mm/in
1030 / 40.6
DEPTH mm/in
460 / 18.1
WEIGHT kg
108
MATERIAL
ELECTRO GALVANIZED MILD STEEL
CASING THICKNESS mm/in
1.0 - 2.3 (0.0393 -0.0905)
FINISHING
EPOXY POLYESTER POWDER COATING
SOUND PRESSURE LEVEL dBA
61
TYPE
FLARE VALVE
SIZE LIQUID mm/in
12.7 / 1/2
GAS mm/in
19.05 / 3/4
PACKING HEIGHT mm/in
1016 / 40.0
DIMENSION WIDTH mm/in
1178 / 46.4
DEPTH mm/in
602 / 23.7
I NDOOR UNI T
FAN
SOUND LEVEL (dBA)
COI L
TUBEFI NTUBEFI N
PI PE
OUTDOOR UNI T
COMPRESSORFANCOI L
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
b) HEATING - 21.1°C DB / 15.6°C WB INDOOR AND 8.3°C DB / 6.1°C WB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
26.7°C DB / 19.4°C WB INDOOR AND 46.1°C DB OUTDOOR
b) HEATING - 21.0°C DB INDOOR AND -8.3°C DB / -9.4°C WB OUTDOOR TO
26.7°C DB INDOOR AND 23.9°C DB / 18.3°C WB
Abbreviation
S.B.C. - SEAMLESS BARE COPPER
S.I.G.C - SEAMLESS INNER GROOVE COPPER
Page 13
