McQuay MCM 025 DR User Manual

Heat Pump (R22)
ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING CAPACITY IS BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
Abbreviation
M ODEL I NDOOR UNIT
MCM06 2CR
OUTDOOR UNIT
MLC061CR
NOM INA L k cal/h
14110
COOLING W
16410
CAPACITY Btu/h
56000
NOM INA L k cal/h
14110
HEAT ING W
16410
CAPACITY Btu/h
56000
NOMINAL TOTAL POWER (COOLING) W
6195
NOMINAL TOTAL POWER (HEATING) W
5265
NOMINAL TOTAL CURRENT (COOLING) A
30.6
NOMINAL TOTAL CURRENT (HEATING) A
26.0
POWER SOURCE V /Ph/Hz
230 / 1/ 60
REFRIGERANT / CONTROL
R22 / CA PILLA RY TUBE - INDOOR ( COOLING) , OUTDOOR ( HEA TING)
AIR FLOW cfm / L/s
1550 / 732
HIGH
56
MED
53
LOW
46
FAN M OTOR
2 x 4 POLES x 80 W
RAT ED INPUT POWER W
338
RAT ED RUNNING CURRENT A
1.60
MATERIAL
S.I.G.C
DI A M ET ER m m / i n
9.52 / 3/8
THICKNESS mm /in
0.35 / 0.014
MATERIAL
A LUMINIUM
THICKNESS mm /in
0.11 / 0.0043
ROW
4
FIN PER INCH
14
FACE AREA m
2
/ft
2
0.42 / 4.51
HEIGHT m m /in
285 / 11.2
DIMENSION WIDTH mm/in
1903 / 74.9
DEPTH mm /in
680 / 26.8
WEIGHT k g
85
CONT ROL ROOM TEM PERAT URE
MICROCOMPUTER CONTROLL ED THERMOSTA T
OPERATION
LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
CONDENSAT E DRAIN SI Z E m m /in
19.05 / 3/4
AIR FILTER
WA SHA BL E SA RA N NET
PACKING HEIGHT m m /in
368 / 14.5
DIMENSION WIDTH mm/in
1984 / 78.1
DEPTH mm /in
760 / 29.9
POWER SOURCE V/Ph/Hz
230 / 1 / 60
COMPRESSOR TYPE
SCROLL
CAPACITOR µF
70
LOCK ROTOR AMP. A
144.0
RAT ED RUNNING CURRENT ( C OOL I N
G
A
27.3
RAT ED RUNNING CURRENT ( HEAT ING A
22.7
RAT ED INPUT POWER (C OOL I NG) W
5500
RAT ED INPUT POWER (HEAT ING) W
4570
PROTECT ION DEV ICE
OV ERLOA D PROTECTION / HI PRESSURE SWITCH
POWER SOURCE V/Ph/Hz
230 / 1 / 60
FAN TYPE / DRIVE
PROPELLER / DIRECT
BLADE MATERIAL
GLASS R. ACRLY STYLENE RESIN
DI A M ET ER m m / in
600 / 24
RAT ED RUNNING CURRENT A
1.7
MOTOR OUTPUT W
160
RAT ED INPUT POWER W
357
MATERIAL
S.I.G.C
DI A M ET ER m m / i n
9.52 / 3/8
THICKNESS mm /in
0.35 / 0.014
MATERIAL
A LUMINIUM ( CORRUGA TED)
THICKNESS mm /in
0.127 / 0.005
ROW
3
FIN PER INCH
14
FACE AREA m
2
/ft
2
0.84 / 9.04
HEIGHT m m /in
850 / 33.5
DIMENSION WIDTH mm/in
1030 / 40.6
DEPTH mm /in
460 / 18.1
WEIGHT k g
108
MATERIAL
EL ECTRO GA L V A NIZ ED MILD S TEEL
CASING THICKNESS m m /in
1.0 - 2.3 (0.0393 -0.0905)
FINISHING
EPOX Y PO L Y ESTER POWDER COA TING
SOUND PRESSURE L EV EL d BA
61
TYPE
FLARE VALVE
SIZE LIQUID mm /in
12.7 / 1/2
GAS mm/in
19.05 / 3/4
PACKING HEIGHT m m /in
1016 / 40.0
DIMENSION WIDTH mm/in
1178 / 46.4
DEPTH mm /in
602 / 23.7
INDOOR UNIT
FAN
SOUND LEV EL ( dBA)
COIL
TUBEFINTUBEFIN
PI PE
OUTDOOR UNIT
COMPRESSORFANCOIL
1) ALL SPECIFICATIONS
S.B.C. - SEAMLESS BARE COPPER
S.I.G.C - SEAMLESS INNER GROOVE COPPER
Page 8
