DC Inverter U-match Series Floor Ceiling Type Unit
32
Type Unit.
Fig. 6.1
States of the Indicating Lamps:
1). Indicating Lamp of “POWER”: The indicating lamp will shine when power on,
while it will go out when power off.
2). Indicating Lamp of “COOL” :
The indicating lamp will shine when “COOL” is activated, while it will go out when
“COOL” is deactivated.
3). Indicating Lamp of “HEAT”:
The indicating lamp will shine when “HEAT” is activated, while it will go out when “HEAT” is
deactivated.
4). Indicating Lamp of “TIMER”
：
The indicating lamp will shine when “TIMER” is activated, while it will go out when
“TIMER” is deactivated or the set.
7.2 Working Temperature Range
Table 6.2
Note:
①
.
The design of this unit conforms to the requirements of ISO5151 standard.
②
.
The air volume is measured at the relevant standard external static pressure.
