Model : MWH060/070B
NO. PART DESCRIPTION AMO
UNT
NO. PART DESCRIPTION AMO
UNT
1 ASSY. CONTROL
BOX ASSEMBLY
1 15 COIL ASSEMBLY 1
2 ASSY.COMPRESSOR
SUPPORT PANEL
1 16 ASSY. FILTER SUPPORT PANEL
TOP AND BOTTOM
1
3 ASSY. BASE PANEL 1 17 TUBE(1 SUIT) 1
4 ASSY. BOTTOM CHECK PANEL 1 18 ASSY. TOP PANEL 1
5 ASSY. WELD HOOK 5 19 ASSY. CHECK PANEL BACK 1
6 ASSY. FRONT CHECK PANEL 1 20 FILTER 2
7 ASSY. BLOWER FLANGE 1 21 ASSY. SIDE PANEL BACK MIDDLE 1
8 ASSY. SIDE PANEL RIGHT 1 22 ASSY. SIDE PANEL BACK RIGHT 1
9 ASSY. COMPRESSOR 2 23 ASSY. CONDENSER 1
10 ASSY. FRONT PANEL 1
11 ASSY. BLOWER 1
12 ASSY. CHECK PANEL LEFT 1
13 ASSY. DRAIN PEN 1
14 ASSY. MIDDLE PANEL 1
To Next Page
