McQuay MWM 007F User Manual

Model : MWM 020F / 020FR / 025F / 025FR / 030F / 030FR
1. ASSY. CHASIS 8. ASSY. EVAPORATOR COIL
2. PIPING, CLAMP 9. ASSY. AIR DISCHARGE HOUSING
3. ASSY. CONTROL BOX 10. CROSS FLOW FAN
4. ASSY. CONTROL BOX COVER 11. SCREW, SELF TAPPING ROUND HEAD
5. ASSY. MOUNTING PLATE 12. SCREW, SELF TAPPING PAN HEAD
6. ASSY. FAN MOTOR 13. WASHER, INT. TEETH STAR
7. ASSY. FRONT COVER 14. SCREW, PAN HEAD MACHINED
