14
Application Information
Cable Size
Model Unit MWM07/10/15/20/25LW MWM301W
MCK020/025/030/
040/050AW
Power supply cable size* mm² 1.5 2.5 1.5
Number of wire 3 3 3
Recommended fuse* A 2 20 2
Model Unit
MCK020/025/030/
040/050AWH
MCM020/025/
030/040/050DW
MCM015/020EW
Power supply cable size* mm² 1.5 1.5 2.5
Number of wire 3 3 3
Recommended fuse* A 2 2 2
Model Unit MCM025EW MCK10/15/20CW MCK20/25/30/40/50EW
Power supply cable size* mm² 4.0 1.5 1.5
Number of wire 3 3 3
Recommended fuse* A 2 2 2
Model Unit MCC10/15/20/25/28CW MCC30/38/40CW MCC50/60CW
Power supply cable size* mm² 1.5 1.5 1.5
Number of wire 3 3 3
Recommended fuse* A 5 10 16
Model Unit MDB75/100BW MDB125/150BW
Power supply cable size* mm² 1.5 1.5
Number of wire 3 4
Recommended fuse* A 5 5
Important: * These values are for information only. They should be checked and selected to comply local
or national codes and regulations. They are also subjected to the type of installation and size of
conductors.
