Selection Process
Selection Process
The following table summarizes the pulley data, motor size used for the MDB series, as manufactured:
Model
Pulley Center Distance, C
Motor, kW Motor RPM
Motor Pulley
Diameter, Dm
Blower Pulley, Db
Horizontal Vertical Taper # Taper #
(mm) (mm) (mm) (mm)
MDB125BW 340 350 1.5 1500 80 150
MDB150BW 320 N/A 2.2 1500 80 160
