MWM-J-2009 Engineering & Physical Data
General Data - Heat pump (R22)
MODEL
INDOOR UNIT MWM009JR MWM015JR
OUTDOOR UNIT MLC009CR MLC015CR
NOMINAL COOLING CAPACITY
Btu/h 8400 11800
W 2460 3460
NOMINAL HEATING CAPACITY
Btu/h 9000 13000
W 2640 3810
NOMINAL TOTAL INPUT POWER (COOLING)
W 925 1192
NOMINAL TOTAL INPUT POWER (HEATING) W 750 1064
NOMINAL RUNNING CURRENT (COOLING) A 4.10 5.50
NOMINAL RUNNING CURRENT (HEATING) A 3.40 4.90
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 2.66 2.90
COP W/W 3.52 3.58
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 145 / 309 163 / 346
MEDIUM l/s / CFM 125 / 265 138 / 293
LOW l/s / CFM 105 / 223 113 / 240
SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 32 / 29 38 / 32 / 27
UNIT DIMENSION
HEIGHT mm/in 288 / 11.3 288 / 11.3
WIDTH mm/in 800 / 31.5 800 / 31.5
DEPTH mm/in 204 / 8.0 204 / 8.0
PACKING DIMENSION
HEIGHT mm/in 350 / 13.8 350 / 13.8
WIDTH mm/in 874 / 34.4 874 / 34.4
DEPTH mm/in 280 / 11.0 280 / 11.0
UNIT WEIGHT kg/lb 12 / 26.5 12 / 26.5
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW l/s / CFM 349 / 740 457 / 969
SOUND PRESSURE LEVEL dBA 45 49
UNIT DIMENSION
HEIGHT mm/in 475 / 18.7 540 / 21.3
WIDTH mm/in 600 / 23.6 700 / 27.6
DEPTH mm/in 245 / 9.6 250 / 9.8
PACKING DIMENSION
HEIGHT
mm/in 535 / 21.1 620 / 24.4
WIDTH mm/in 712 / 28.0 810 / 31.9
DEPTH mm/in 320 / 12.6 330 / 13.0
UNIT WEIGHT kg/lb 33 / 72.6 34 / 75.0
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.4 / 1/4 6.4 / 1/4
GAS mm/in 9.5 / 3/8 12.7 / 1/2
REFRIGERANT CHARGE kg/lb 0.65 / 1.43 0.93/2.04
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
