Outline and Dimension MWM-J-2009
45
Outline and Dimension
Indoor Unit
Model: MWM009/015J/JR, M5WM010/015J/JR
800
288
TOP VIEW
FRONT VIEW
206
SIDE VIEW
288
LOUVER
50123456789 Note: Dimension in mm
Outdoor Unit
Model: MLC009/015C/CR, M5LC010/015C/CR
3
)1.0(
B
FE
NCN
KLL
M
30
)
2.
1(
A
D
19
)
7
.
0
(
C
GH
IJ
O
80
3(
.
)1
65
2(
.
)6
Dimension A B C D E F G H I J K L M N O
10 / 15C / CR
700 521 250 485 175 36 95 93 86 68 441 130 111 15 18
(27.5) (20.5) (9.8) (19.1) (6.8) (1.4) (3.7) (3.6) (3.3) (2.6) (17.3) (5.1) (4.3) (0.5) (0.7)
50123456789 Note: Dimension in mm
Catalog.indb 45Catalog.indb 45 3/2/2009 4:41:27 PM3/2/2009 4:41:27 PM

McQuay MWM009J Specifications

General

Brand	McQuay
Model	MWM009J
Category	Air Conditioner
Language	English
